Schneider C120L 1P D 125A (A9) Miniature Circuit Breaker

Name: Schneider C120L 1P D 125A (A9) Miniature Circuit Breaker
SKU: A9N19860

Brand:

Schneider

Series:

C120 (A9)

Rated Current:

125A

Trip Characteristics:

Poles:

Rated Voltage:

230VAC

Breaking Capacity:

15KA

Model:

C120L 1P D 125A (A9)

Order Number:

A9N19860

Description:

Schneider miniature circuit breaker C120L 1P D 125A (A9), breaking capacity 15KA, trip characteristic D, 230VAC, 125A

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Schneider
Series：	C120 (A9)
Rated Current：	125A
Trip Characteristics：	D
Poles：	1P
Rated Voltage：	230VAC
Breaking Capacity：	15KA

Products with the same attribute : 0

Show details

Series Overview

High-Quality Modular Distribution System

VisiSafe 'Visible Safety' – Under any environment and condition, VisiSafe ensures absolute reliable safety for downstream circuits.

• VisiSafe green indicator strip reliably shows the open position of the contacts.

• Impulse withstand voltage: Uimp=6kV – Ensures effective improvement of equipment lifespan even under overvoltage conditions.

• Highest pollution degree in modular products: Degree 3 – Promises a product truly suitable for harsh environments, including those with dust and conductive pollution.

• Insulation voltage: 500V – Guarantees absolute safety for operator handling.

Shock Protection Class: Class 2

Acti9 is currently the only device with this safety level. The electrical clearance between the surface of the circuit breaker and internal parts exceeds twice the standard requirement. Regardless of the environment or operator experience, Acti9 guarantees risk-free maintenance and use throughout the entire service life of the equipment.

Full Range Quick Closing

Acti9's quick closing function limits energy release during contact closure, thereby helping prevent equipment overheating and aging.

Reliable Clamping

Acti9 terminals can withstand a tightening torque equivalent to twice the national standard torque, making cable connections more reliable and secure.

Integrated Padlocking Mechanism

Acti9's remote control devices use a robust integrated padlocking mechanism, allowing complete locking for safety. It prevents unintentional or unauthorized remote operation of power supply equipment, thus ensuring absolute operator safety.

C120H Circuit Breaker, suitable for high-power consumption locations, enables:

• Protection and control of high-current loads.

• Overload and short-circuit protection for distribution lines.

• Manual control and breaking.

• Use with residual current protection accessories (Vigi C120) without derating.

C120L Circuit Breaker, suitable for high-power consumption locations, enables:

• Protection and control of high-current loads.

• Overload and short-circuit protection for distribution lines.

• Manual control and breaking.

• Use with residual current protection accessories (Vigi C120) without derating.
