Schneider OSMC32N-B20A/3P Miniature Circuit Breaker
Brand:
Series:
OSMC32N
Rated Current:
20A
Trip Characteristics:
B
Poles:
3P
Rated Voltage:
400VAC
Breaking Capacity:
6KA
Model:
OSMC32N-B20A/3P
Order Number:
OSMC32N3B20
Description:
Schneider miniature circuit breaker OSMC32N-B20A/3P, breaking capacity 6KA, trip characteristic B, 400VAC, 20A
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Schneider | |
| Series： | OSMC32N | |
| Rated Current： | 20A | |
| Trip Characteristics： | B | |
| Poles： | 3P | |
| Rated Voltage： | 400VAC | |
| Breaking Capacity： | 6KA |
Products with the same attribute : 0
Show details
Series Overview
Introduction
• The new generation of Osart series miniature circuit breakers features a more comprehensive current rating range, clearer model selection labeling, distinctive series identification and packaging tailor-made for OEM customers, and a more complete range of accessories... Designed with the needs and market characteristics of industrial control and original equipment manufacturers in mind, it leverages Merlin Gerlin's leading technology and mature experience, prioritizing product reliability and high quality while emphasizing practicality and ease of installation.
Market Positioning - Tailor-made for CEM
• Providing excellent low-voltage distribution product solutions and services for CEMs, the Osart series miniature circuit breakers are primarily used for protecting various industrial equipment and industrial control cabinets within OEM applications. They are not suitable for protecting low-voltage distribution systems in building applications.
Modular Product
• The Osart series miniature circuit breakers are modular products, with each module standardized to a width of 9mm, simplifying complexity.
Certifications
• The Osart series miniature circuit breakers have passed comprehensive certifications including CCC, CE, UL, TÜV, CCS, and others, fully meeting the requirements for domestic use and equipment export by OEM users. They comply with the EU RoHS Directive and REACH regulations.
Installation
• They can be easily installed on DIN standard rails without special tools. Performance remains unaffected when installed side-by-side. The bistable locking clip ensures more convenient installation.
Connection
• The products utilize tunnel-type terminals. This design facilitates correct wire positioning, ensures a more secure crimp, and effectively reduces terminal overheating and burnout caused by poor connections.
Function
• The OSMC 32N miniature circuit breaker offers the following functions:
• Short-circuit protection
• Overload protection
• Control
• Isolation
Specifications
Standards and Certifications:
• Complies with IEC 60898 / GB 10963.1
• Certifications: CCC, CE, CCS
• Complies with RoHS and REACH
