Shanghai Renmin RMC3-125D/2P 63A Miniature Circuit Breaker

Brand:

Shanghai Renmin

Series:

RMC3-125

Rated Current:

63A

Trip Characteristics:

Poles:

Rated Voltage:

400/415VAC

Breaking Capacity:

10KA

Model:

RMC3-125D/2P 63A

Order Number:

Description:

Shanghai Renmin miniature circuit breaker RMC3-125D/2P 63A, breaking capacity 10KA, trip characteristic D, 400/415VAC, 63A

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Shanghai Renmin
Series：	RMC3-125
Rated Current：	63A
Trip Characteristics：	D
Poles：	2P
Rated Voltage：	400/415VAC
Breaking Capacity：	10KA

Products with the same attribute : 0

Show details

Series Overview

Series Overview

ShangLian RMC3 series miniature circuit breakers comply with the stipulations of the following standards: IEC 60898-1, GB/T 10963.1 Circuit-breakers for overcurrent protection for household and similar installations - Part 1: Circuit-breakers for a.c. operation, IEC 60947-2, GB/T 14048.2 Low-voltage switchgear and controlgear - Part 2: Circuit-breakers, IEC 60947-3, GB/T 14048.3 Low-voltage switchgear and controlgear - Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units, IEC 61009-1, GB/T 16917.1 Residual current operated circuit-breakers with integral overcurrent protection for household and similar uses (RCBOs).

Features

● Short-circuit current limiting structure - High rated short-circuit breaking capacity

● Equipped with overload and short-circuit protection devices

● Utilizes "frame-type" terminal structure - Safe and reliable wiring

● Compatible with various accessories: Residual Current Operated Circuit-Breakers (RCBOs), auxiliary contacts, alarm contacts, shunt releases, undervoltage releases, over/under-voltage releases.

● Modular and standardized modular dimensions - Allows arbitrary combinations and series matching

● Mounts on TH35mm standard DIN rail - Simple and convenient installation

● Auxiliary contacts, alarm contacts, shunt releases, undervoltage releases, over/under-voltage releases - Facilitates easy functional expansion

Normal Service Conditions

● Ambient temperature: -5°C to +40°C

● Altitude: ≤ 2000m

● Relative air humidity: ≤ 90%

Functions

● Short-circuit protection

● Isolation protection

● Overload protection

● Visible contact break indication window
