Siemens 5SN6620-8CN(D20 3P+N 6KA) Miniature Circuit Breaker
Brand:
Series:
5SN
Rated Current:
20A
Trip Characteristics:
D
Poles:
3P+N
Rated Voltage:
230/400VAC
Breaking Capacity:
6KA
Model:
5SN6620-8CN(D20 3P+N 6KA)
Order Number:
5SN66208CN
Description:
Siemens miniature circuit breaker 5SN6620-8CN (D20 3P+N 6KA), breaking capacity 6KA, trip characteristic D, 230/400VAC, 20A
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | 5SN | |
| Rated Current： | 20A | |
| Trip Characteristics： | D | |
| Poles： | 3P+N | |
| Rated Voltage： | 230/400VAC | |
| Breaking Capacity： | 6KA |
Products with the same attribute : 0
Show details
Series Overview
Typical Applications
Building Specific Applications
Unique Advantages
Dust-proof and finger-safe
Sliding latch
Compact design
Energy saving and efficiency improvement
Fully enclosed dust-proof terminal design
Rectangular terminals facilitate easier connection of pin busbars and conductors, with wiring capacity ranging from 0.75 to 35 mm².
The terminal design incorporates finger-safe protection, not only serving as dust-proof but also ensuring personnel safety.
Product disassembly requires no tools.
When installed on busbars, product disassembly requires no auxiliary tools, making it easy and convenient.
Energy saving and efficiency improvement
Outstanding low energy consumption, significantly lower than the power consumption defined by IEC and national standards. Actual measurements are only approximately one-third to one-half of the standard definition. Saves electricity with evident benefits.
Ergonomically designed operating handle and form factor highlight a human-centric approach.
The sliding latch design makes installation and disassembly onto the mounting rail or busbar easier and faster.
Consistent busbar design concept
A busbar design concept applied across all Siemens circuit breaker products, maximizing universality.
The product provides a larger wiring area, while busbar installation becomes easier and safer.
Dust-proof and finger-safe
To ensure the safety of customer installation and wiring, the insulated dust-proof and finger-safe design significantly extends product lifespan while minimizing the risk of electric shock.
Sliding latch
The unique sliding latch design makes disassembly from busbars or mounting rails simpler and quicker, significantly improving efficiency.
Compact design
The compact Residual Current Circuit Breaker (RCCB) design has a width of only 18mm, while offering both Type A and Type AC residual current protection. It saves space while providing more comprehensive electric shock protection.
5SN6..CN Product Features
- Handle with switch status indication function for easy observation and identification.
- Completely finger-safe and isolated terminal design, effectively dust-proof, ensuring installation and operational protection.
- Sliding latch design makes disassembly from busbars or mounting rails easier.
- Consistent busbar design enables universal compatibility across all products.
