Legrand RX3R-D20/3P/100E Micro Leakage Protection Circuit Breaker

Name: Legrand RX3R-D20/3P/100E Micro Leakage Protection Circuit Breaker
SKU: 413409AE

Brand:

Legrand

Series:

RX3

Leakage Protection Type:

Leakage Tripping Type:

ELE (Electronic)

Leakage Current:

100mA

Rated Current:

20A

Trip Characteristics:

Poles:

Rated Voltage:

400VAC

Breaking Capacity:

6KA

Model:

RX3R-D20/3P/100E

Order Number:

413409AE

Description:

RX3R-D20/3P/100E, trip device characteristic D, leakage current 100mA, 20A, breaking capacity 6KA, ELE, pole number 3P, 400VAC

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Legrand
Series：	RX3
Leakage Protection Type：	AC
Leakage Tripping Type：	ELE (Electronic)
Leakage Current：	100mA
Rated Current：	20A
Trip Characteristics：	D
Poles：	3P
Rated Voltage：	400VAC
Breaking Capacity：	6KA

Products with the same attribute : 0

Show details

Series Overview

Product Overview

• RX3 series MCBs and RCBOs meet electrical requirements for residential and small commercial areas, providing comprehensive safety solutions with overload protection, short-circuit protection, and residual current protection. They satisfy diverse building needs: dual tripping characteristic curves, multiple breaking capacities, and earth leakage protection.

RCBOs

• In: 6-63A

• Poles: 1P+N, 2P, 3P, 3P+N, 4P

• Breaking capacity: 4.5kA, 6kA

• Rated residual operating current: 30mA AC

• Tripping characteristics: Curve C, Curve D

• Compliance standards: GB 16917.1, GB 16917.22

MCBs

• In: 6-63A

• Poles: 1P, 1P+N, 2P, 3P, 4P

• Breaking capacity: 4.5kA, 6kA

• Tripping characteristics: Curve C, Curve D

• Compliance standards: IEC 60898-1, GB 10963.1

Quick and Simple Wiring

• IP2X protection rating

• 35mm² wiring capacity

• Secure terminal blocks

• Compatible with flat-head screwdrivers

Clear Visual Markings

• Non-obstructive handle design maintains label visibility

• Durable laser-printed markings with high clarity

Bistable Mounting Structure

• Easy placement/removal on DIN rails

Optimized Safety Design

• Precision-engineered dimensions and selected materials ensure airflow between adjacent breakers, limiting temperature rise.

RX3 Reliability Assurance

• Mechanical endurance: 10,000 operations

• Operating temperature: -25℃ to +70℃

• Current limiting class: Class 3

• Certifications: CCC, CE

• Environmental standard: RoHS

Rachel

Industrial Control Sales Specialist: Focuses on delivering high-performance, cost-effective industrial control products. Offers end-to-end one-stop procurement support—covering rapid quotation, streamlined order fulfillment, and responsive after-sales service—to simplify clients’ procurement processes. Email: Anthony@icxsg.com

We offer competitive product pricing. For fast support, send your email, phone, address, and the product model & quantity you want—we’ll reach out quickly!
