SHT ZB5L-63/2P C25A 30MA micro leakage protection circuit breaker

Brand:

SHT

Series:

ZB5

Leakage Protection Type:

Leakage Tripping Type:

ELE (Electronic)

Leakage Current:

30mA

Rated Current:

25A

Trip Characteristics:

Poles:

Rated Voltage:

230/400VAC

Breaking Capacity:

10KA

Model:

ZB5L-63/2P C25A 30MA

Order Number:

Description:

ZB5L-63/2P C25A 30MA, trip characteristic C, leakage current 30mA, 25A, breaking capacity 10KA, ELE, pole number 2P, 230/400VAC

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	SHT
Series：	ZB5
Leakage Protection Type：	AC
Leakage Tripping Type：	ELE (Electronic)
Leakage Current：	30mA
Rated Current：	25A
Trip Characteristics：	C
Poles：	2P
Rated Voltage：	230/400VAC
Breaking Capacity：	10KA

Products with the same attribute : 0

Show details

Series Overview

Product Description

• ZB5L Residual Current operated Circuit-Breakers (hereinafter referred to as circuit-breakers) are newly developed products by Shanghai Huatong. Suitable for AC 50/60Hz circuits with rated voltages of 230V/400V and rated currents from 6A to 63A, they rapidly cut off power when residual currents exceed set values, ensuring safety for personnel and electrical equipment. They also provide overload/short-circuit protection and allow infrequent switching operations.

• Complies with GB 16917.1 (IEC 61009-1).

Product Advantages

• Compact structure

• Aesthetic appearance

• High breaking capacity

• Convenient and secure wiring

• Reversible line connection

Operating and Installation Conditions

• Ambient temperature: -25℃ to +55℃; 24-hour average ≤ +35℃

• Altitude: ≤3,000m

• Relative humidity:

• ≤50% at +55℃; higher humidity permitted at lower temperatures

• Maximum monthly average relative humidity ≤90% (monthly average temperature ≤ +35℃), with measures against surface condensation

• Pollution degree: Level 2

• Installation category: Classes II and III

• External magnetic fields: ≤5 times Earth's magnetic field in any direction

• Mounting orientation: Typically vertical (handle upward for ON position); installed on 35x7.5mm standard rails

• Environment: No significant shock/vibration

• Additional protection: Under-voltage/over-voltage protection for grid faults:

• Over-voltage setting: 280V ±5%

• Under-voltage setting: 170V ±5%

• Terminal capacity: Maximum conductor cross-section 25mm².
