Schneider C9 DPNA VIGI 1P+N C40A 30MA A ELE Miniature Leakage Protection Circuit Breaker

Name: Schneider C9 DPNA VIGI 1P+N C40A 30MA A ELE Miniature Leakage Protection Circuit Breaker
SKU: C9D24640

Brand:

Schneider

Series:

C9DPN Vigi

Leakage Protection Type:

Leakage Tripping Type:

ELE (Electronic)

Leakage Current:

30mA

Rated Current:

40A

Trip Characteristics:

Poles:

1P+N

Rated Voltage:

230VAC

Breaking Capacity:

4.5KA

Model:

C9 DPNA VIGI 1P+N C40A 30MA A ELE

Order Number:

C9D24640

Description:

C9 DPNA VIGI 1P+N C40A 30MA A ELE, trip unit characteristic C, leakage current 30mA, 40A, breaking capacity 4.5KA, ELE, poles 1P+N, 230VAC

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Schneider
Series：	C9DPN Vigi
Leakage Protection Type：	A
Leakage Tripping Type：	ELE (Electronic)
Leakage Current：	30mA
Rated Current：	40A
Trip Characteristics：	C
Poles：	1P+N
Rated Voltage：	230VAC
Breaking Capacity：	4.5KA

Products with the same attribute : 0

Show details

Series Overview

C9 Series Introduction

Safety and Reliability

• C9 series products feature core professional design and technology, providing robust protection for personal and property safety during installation and operation.

Ease of Use

• C9 series offers tunnel-type terminals, bistable locking clips, and ergonomic handles, ensuring exceptional convenience throughout installation and operation.

Comprehensive Applications

• C9 series delivers a full product range with extensive parameters, meeting diverse industrial demands and harsh environment requirements.

Eco-Friendly Design

• Free from environmentally hazardous substances. 100% recyclable thermoplastic housing minimizes energy loss from heat generation.

Product Certifications

• C9 series products are CCC and CE certified, with additional RoHS and REACH environmental compliance.

C9 Industry Applications

• C9 low-voltage terminal distribution series offers superior quality, complete range, and full certifications, delivering comprehensive circuit protection, optimal user experience, and cost-effectiveness across industries.

Construction Industry Applications

• Full product series covering 1–125A current range; electrical accessories include residual current protection and overvoltage/undervoltage accessories. With CCC and CE certifications for residential/commercial buildings.

OEM Industry Applications

• Complete circuit breaker series with current ratings up to 125A, fully compatible with communication power supplies, DC panels, and other low-voltage OEM applications.

C9DPN Vigi Residual Current Circuit Breaker Functions

• Provides comprehensive protection for terminal distribution circuits. Breaks both phase and neutral lines simultaneously, with no protection function on the neutral line. Capabilities include:

• Short-circuit protection

• Overload protection

• Isolation function

• Personal protection against indirect contact

• Supplementary personal protection against direct contact

• Protection against insulation faults in electrical equipment
