ABB A1N125 TMF100/1000 FF 4P Molded Case Circuit Breaker
Brand:
Series:
Formula A
Protection Type:
Power distribution protection
How It Works:
Manual
Frame Current:
125A
Tripping Mode:
Thermal Magnetic
Protection Function:
LI
Wiring Method:
Front panel wiring
Poles:
4P
Rated Voltage:
415VAC
Installation:
Fixed
Trip Unit:
TMF
Rated Current of Release:
100A
Breaking Capacity:
36KA
Model:
A1N125 TMF100/1000 FF 4P
Order Number:
10116379
Description:
ABB molded case circuit breaker A1N125 TMF100/1000 FF 4P,LI,distribution protection,36KA,125A,fixed,manual,4P
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | ABB | |
| Series： | Formula A | |
| Appendix： | - | |
| Protection Type： | Power distribution protection | |
| How It Works： | Manual | |
| Frame Current： | 125A | |
| Tripping Mode： | Thermal Magnetic | |
| Protection Function： | LI | |
| Wiring Method： | Front panel wiring | |
| Poles： | 4P | |
| Rated Voltage： | 415VAC | |
| Installation： | Fixed | |
| Trip Unit： | TMF | |
| Rated Current of Release： | 100A | |
| Breaking Capacity： | 36KA |
Products with the same attribute : 0
Show details
Series Overview
FORMULA Series Overview Outline
Combining simplicity and quality
● The FORMULA series consists of three frames: A1, A2, and A3, with frame currents of 125A, 250A, and 630A respectively.
● All three frames are fixed type and come standard with front terminals.
● Factory pre-set thermal-magnetic trip units offer straightforward selection, enabling easy on-site installation, avoiding setting errors, and facilitating use by equipment manufacturers' personnel and future spare part replacement for customers.
● Compact size, easy ordering, simple installation, and quick setup provide users with unprecedented simplicity.
Main Features:
Simple configuration, easy selection and ordering
● Multiple accessories available
● Significantly reduced depth
● Simple and accurate selection
● FORMULA integrates ABB's high quality, high reliability, and simplicity into one, making it a truly simple and practical molded case circuit breaker.
● Reduced dimensions while still ensuring excellent performance and reliability, offering a higher performance-to-size ratio than all comparable circuit breakers on the market. This provides users with more space for cable routing and reduces switchgear size.
● The compact size offers significant advantages, especially for UEM manufacturers, panel builders, and installers.
● FORMULA A1 and A2 are the only high-performance circuit breakers achieving 250A current within a 60mm depth.
All FORMULA series molded case circuit breakers feature the following characteristics:
● Double insulation
● Reliable operation
● Isolation function
● Electromagnetic compatibility
● Top or bottom power connection
● Multi-directional installation: the circuit breaker can be installed horizontally, vertically, or on its side without any impact on performance.
● No derating required up to 2000m above sea level. Above 2000m, changes in atmospheric conditions (air composition, dielectric strength, cooling capacity, and atmospheric pressure) affect the main parameters of the circuit breaker.
● FORMULA series circuit breakers operate normally at ambient temperatures from -25°C to +70°C. Storage temperature ranges from -40°C to +70°C.
● All FORMULA circuit breakers feature a test button for trip testing. Testing is only possible in the closed position.
● FORMULA A3 can be configured with a dedicated white handle for convenient manual operation.
Compliance
Standards:
● IEC 60947-2, GB14048.2-2008
Directives:
● EC Directive: "Low Voltage Directive" (LVD) no. 2006/95/EC
● EC Directive: "Electromagnetic Compatibility Directive" (EMC) no. 89/336/EEC
General Characteristics
FORMULA circuit breakers range from 15A to 630A and can be installed as follows:
● Backplate mounting
● DIN rail mounting (A1 and A2)
● Rear mounting plate (A1, A2, and A3)
Product Features
● Fixed type
● Number of poles: 3-pole and 4-pole
● Maximum breaking capacity (415V AC): 36kA (A1 and A2), 50kA (A3)
● TMF thermal-magnetic trip units usable in AC and DC networks (A1, A2, A3)
● ELT LI electronic trip unit usable in AC networks (A3)
● Only 2 depths: 60mm (A1, A2), 103.5mm (A3)
● Standard front terminals
