ABB P1N 160 TMD 40-450 3P FF Molded Case Circuit Breaker
Brand:
Series:
Formula DSP
Protection Type:
Power distribution protection
How It Works:
Manual
Frame Current:
160A
Tripping Mode:
Thermal Magnetic
Protection Function:
LI
Wiring Method:
Front panel wiring
Poles:
3P
Rated Voltage:
415VAC
Installation:
Fixed
Trip Unit:
TMD
Rated Current of Release:
40A
Breaking Capacity:
36KA
Model:
P1N 160 TMD 40-450 3P FF
Order Number:
10251123
Description:
ABB molded case circuit breaker P1N 160 TMD 40-450 3P FF,LI,distribution protection,36KA,160A,fixed,manual,3P
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | ABB | |
| Series： | Formula DSP | |
| Appendix： | - | |
| Protection Type： | Power distribution protection | |
| How It Works： | Manual | |
| Frame Current： | 160A | |
| Tripping Mode： | Thermal Magnetic | |
| Protection Function： | LI | |
| Wiring Method： | Front panel wiring | |
| Poles： | 3P | |
| Rated Voltage： | 415VAC | |
| Installation： | Fixed | |
| Trip Unit： | TMD | |
| Rated Current of Release： | 40A | |
| Breaking Capacity： | 36KA |
Products with the same attribute : 0
Show details
Series Overview
FORMULA DSP Overview
● The new FORMULA DSP series includes four frame sizes (P1, P2, P3, and P4), rated at 160A, 250A, 630A, and 800A respectively. All four frame sizes are equipped with thermal-magnetic releases, covering AC and DC applications. A rich selection of accessories meets the application needs of the building sector.
● Easy Installation: Snap-on mounting accessories ensure time savings and quick installation completion.
● Simplified Selection: Provides a concise code table to simplify product selection and facilitate ordering.
● Wide Application Range: Covers standard applications in residential, commercial, and industrial buildings.
● Safety and Reliability: Complies with major safety standards and directives.
● Standardization: Shares the same dimensions as the SACE Tmax XT series, ensuring solution standardization across the entire ABB molded case circuit breaker range.
● Tailored Solution: Product performance meets the needs of civil and commercial building applications, tailor-made for building customers.
● Quality: ABB's long-term experience in molded case circuit breaker design guarantees quality.
● Sustainability: Complies with international regulations for product materials, environmental health, and safety.
Product Compliance
Compliance with Standards
● FORMULA DSP circuit breakers and their accessories are manufactured in compliance with the following standards:
● Standards:
● IEC 60947-2;
● GB/T 14048.1 General Rules;
● GB/T 14048.2 Circuit-breakers.
● Directives:
● EC "Low Voltage Directive" (LVD) 2014/35/EU;
● EC "Electromagnetic Compatibility Directive" (EMC) 2014/30/EU.
Product Material Standards
● The FORMULA DSP series complies with the following international standards:
● RoHS II, Directive 2011/65/EU and Amendment 2015/863 - Restriction of Hazardous Substances;
● REACH, 2006/1907/EC, Registration, Evaluation, Authorisation and Restriction of Chemicals;
● WEEE 2012/19/EU - Waste Electrical and Electronic Equipment Directive;
● Conflict Minerals - Dodd-Frank Act Section 1502.
Structural Characteristics
● All FORMULA DSP molded case circuit breakers are designed and manufactured according to the following structural characteristics.
Double Insulation
● FORMULA DSP circuit breakers feature double insulation between live parts (excluding terminals) and the front parts of the equipment manipulated by the operator during normal operation.
● The base of each electrical accessory is completely isolated from the power circuit, preventing contact with live parts. In particular, the operating mechanism is completely isolated from the supply circuit.
● Additionally, there are oversized insulation distances between live internal parts of the circuit breaker and near the terminal connections. These distances exceed those required by the IEC standard.
Insulation Performance
● In the OFF position, the circuit breaker guarantees insulation distances complying with the requirements of the IEC 60947-2 standard, thus avoiding leakage current between the input and output terminals.
Tropical Climate Suitability
● Circuit breakers and accessories in the FORMULA DSP series were tested twice at 55°C using "variant 1" method (clause 7.3.3) according to IEC 60068-2-30 standard.
● The suitability of the FORMULA DSP series for the most severe environmental conditions is further ensured based on the following reasons:
● Insulating enclosures are made of glass fiber reinforced synthetic resin;
● Main metal parts undergo anti-corrosion treatment;
● Coatings provide Fe/Zn 12 zinc plating (ISO 2081) protection, free from hexavalent chromium (compliant with RoHS), achieving ISO 4520 Class C corrosion resistance.
