CS Switch CM5Z-400L/3/IPN25T/00 100A(40-100) Molded Case Circuit Breaker
Brand:
Series:
CM5Z
Protection Type:
Power distribution protection
How It Works:
Manual
Frame Current:
400A
Tripping Mode:
Electronic
Protection Function:
LSI
Wiring Method:
Front panel wiring
Poles:
3P
Rated Voltage:
400VAC
Installation:
Fixed
Trip Unit:
IPN25T
Rated Current of Release:
100A
Breaking Capacity:
50KA
Model:
CM5Z-400L/3/IPN25T/00 100A(40-100)
Order Number:
C0126243
Description:
CS Switch Molded Case Circuit Breaker CM5Z-400L/3/IPN25T/00 100A(40-100),LSI,Distribution Protection,50KA,400A,Fixed,Manual,3P
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | CS Switch | |
| Series： | CM5Z | |
| Appendix： | - | |
| Protection Type： | Power distribution protection | |
| How It Works： | Manual | |
| Frame Current： | 400A | |
| Tripping Mode： | Electronic | |
| Protection Function： | LSI | |
| Wiring Method： | Front panel wiring | |
| Poles： | 3P | |
| Rated Voltage： | 400VAC | |
| Installation： | Fixed | |
| Trip Unit： | IPN25T | |
| Rated Current of Release： | 100A | |
| Breaking Capacity： | 50KA |
Products with the same attribute : 0
Show details
Series Overview
Product Series Overview
- CM5Z Molded Case Circuit Breakers (hereinafter referred to as circuit breakers) are a new generation of circuit breakers developed with internationally advanced double-break structure technology.
- The intelligent CM5Z series circuit breakers have six frame sizes: 125A, 160A, 250A, 400A, 630A, and 1600A, with current ratings from 12.5A to 1600A.
- CM5Z intelligent circuit breakers offer various optional intelligent releases, including Type E, Type Z, and Type iP. The iP type provides comprehensive energy monitoring functions and is available for 250, 400, and 630 frame sizes.
- CM5Z-250, 400, and 630 circuit breakers can be quickly and integrally installed using busbar adapters.
- Based on the level of Rated Ultimate Short-Circuit Breaking Capacity (Icu), circuit breakers are classified into seven levels: Type C (Basic), Type L (Standard), Type M (Higher Breaking), Type H (High Breaking), Type S (Ultra High Breaking), Type V (Extreme High Breaking), and Type R (690V High Performance).
- Circuit breakers with short-circuit breaking capacity levels C, L, M, H, and S can be reverse connected at all voltage levels. Type V and Type R cannot be reverse connected at AC 690V.
- Circuit breakers can be mounted vertically or horizontally on vertical mounting plates, or on horizontal mounting plates.
- All circuit breakers have isolation function, indicated by the symbol: 1X.
Standards:
- IEC 60947-1 & GB/T 14048.1-2012 Low-voltage switchgear and controlgear - General rules
- IEC 60947-2 & GB/T 14048.2-2008 Low-voltage switchgear and controlgear - Circuit-breakers
- IEC 60947-3 & GB/T 14048.3-2017 Low-voltage switchgear and controlgear - Switches, disconnectors, switch-disconnectors and fuse-combination units
- IEC 60947-4-1 & GB/T 14048.4-2010 Low-voltage switchgear and controlgear - Contactors and motor-starters - Electromechanical contactors and motor-starters (including motor protection)
- The CM5Z-1600 intelligent molded case circuit breaker features compact size, high breaking capacity, rich functions, and comprehensive protection, with performance indicators reaching internationally advanced levels. Furthermore, the coordination between CM5Z-1600 and the downstream OI5 molded case circuit breaker meets the requirements for full selectivity according to GB/T 14048.2 Appendix A.
- CM5Z-1600 is suitable for low-voltage distribution systems with AC 50/60Hz, rated operational voltages of 400V, 440V, 500V, 550V, 690V, and rated currents from 800A to 1600A. It can protect not only lines but also equipment such as motors and generators. The product can be applied in scenarios like large-capacity transformer branch circuits, centralized load control, long cable power supply, and new energy fields such as photovoltaic power generation.
- CM5Z-1600 intelligent molded case circuit breakers offer various optional intelligent releases, including Type EA, Type EP, Type BQ, Type EN, and Type BG.
- Based on the level of Rated Ultimate Short-Circuit Breaking Capacity (Icu), CM5Z-1600 circuit breakers are classified into four levels: Type L (Standard), Type F (General), Type M (Higher Breaking), Type H (High Breaking).
- CM5Z-1600 circuit breakers can be reverse connected at all voltage levels and for all short-circuit breaking capacity levels.
- CM5Z-1600 circuit breakers can be mounted vertically or horizontally on vertical mounting plates, on horizontal mounting plates, and also in a withdrawable version.
- The circuit breaker has an isolation function, indicated by the symbol: -1x.
Application Scenarios
Low-Voltage Distribution Protection
- CM5Z distribution-type circuit breakers can be used in AC 50/60Hz TN, TT, IT distribution systems, meeting the requirements for "Selection of Electrical Appliances" in GB 50054.
- The reliable contact indication and isolation function of CM5Z circuit breakers meet the requirements for isolation devices in GB 50054.
Motor Circuit Protection
- CM5Z motor protection-type circuit breakers provide overcurrent protection for motor starters, cables, and motors. Their protection characteristics meet GB 14048.4, and their application meets GB 50055.
Generator Protection
- CM5Z-1600 circuit breakers can be equipped with the optional Type BG intelligent release, which not only provides overcurrent protection for generators but also enables over-frequency, under-frequency, and reverse power protection, meeting the requirements of GB 755 standard.
Switching Function
- Two CM5Z circuit breakers equipped with a mechanical interlock mechanism can achieve manual switching between two power sources for the same device or between two devices on the same power source.
- Two mechanically and electrically interlocked circuit breakers, equipped with a controller, can achieve automatic switching between two power sources.
Normal Service and Mounting Conditions
- Ambient air temperature: -5°C to +40°C;
- Altitude at installation site not exceeding 2000m;
- Relative humidity of air at the installation site does not exceed 50% at a maximum temperature of +40°C; higher relative humidity is permissible at lower temperatures, e.g., 90% at 20°C. Special measures should be taken for occasional condensation due to temperature changes;
- Pollution Degree: 3;
- Circuit breakers meet the requirements of GB/T 2423.10, capable of withstanding mechanical vibration with frequency 2Hz~13.2Hz, displacement ±1mm, and frequency 13.2Hz~100Hz, acceleration ±0.7g;
- Installation category of the main circuit: III; Installation category of other auxiliary and control circuits: II;
- Circuit breakers are suitable for Electromagnetic Environment A;
- Tropical humid type (TH type) circuit breakers meet the requirements of GB/T 2423.4 and GB/T 2423.18, capable of withstanding the effects of humid air, salt mist, oil mist, and mold;
- Circuit breakers should be installed in locations without explosion hazard, conductive dust, or conditions sufficient to corrode metals and destroy insulation;
- Circuit breakers should be installed in locations not subject to rain or snow invasion.
Permissible Service Conditions:
- Circuit breakers meet the requirements of GB/T 2423.1 and GB/T 2423.2, allowing ambient air temperatures as low as -25°C (CM5Z equipped with EN, EM intelligent releases can operate down to -40°C) and as high as +70°C (derating applies above +40°C, refer to technical data in the catalog);
- Circuit breakers meet the requirements of GB/T 2423.4 Test Db (temperature +55°C, relative humidity 95%);
- Characteristics unaffected up to an altitude of 2500m (derating applies above 2500m, refer to technical data in the catalog);
- Storage conditions: Ambient air temperature: -25°C to +70°C.
