CS Switch CM5X-125C/4C/3/00 25A Molded Case Circuit Breaker

Name: CS Switch CM5X-125C/4C/3/00 25A Molded Case Circuit Breaker
SKU: C0244919

Brand:

CS Switch

Series:

CM5X

Protection Type:

Main body (with protection function)

How It Works:

Manual

Frame Current:

125A

Tripping Mode:

Thermal Magnetic

Protection Function:

Wiring Method:

Front panel wiring

Poles:

Rated Voltage:

400VAC

Installation:

Fixed

Trip Unit:

Compound release

Rated Current of Release:

25A

Breaking Capacity:

25KA

Model:

CM5X-125C/4C/3/00 25A

Order Number:

C0244919

Description:

CS Switch Molded Case Circuit Breaker CM5X-125C/4C/3/00 25A,LI,25KA,125A,Fixed,Manual,4P

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	CS Switch
Series：	CM5X
Appendix：	-
Protection Type：	Main body (with protection function)
How It Works：	Manual
Frame Current：	125A
Tripping Mode：	Thermal Magnetic
Protection Function：	LI
Wiring Method：	Front panel wiring
Poles：	4P
Rated Voltage：	400VAC
Installation：	Fixed
Trip Unit：	Compound release
Rated Current of Release：	25A
Breaking Capacity：	25KA

Products with the same attribute : 0

Show details

Series Overview

Series Outline

The CM5X and CM5XL Molded Case Circuit Breakers (hereinafter referred to as circuit breakers) are compact breakers developed using double-break structure technology, representing an internationally advanced level. They are categorized as:

· Thermal-magnetic type CM5X-125 circuit breaker, current ratings from 1.5A to 125A;

· Thermal-magnetic type with residual current protection CM5XL-125 circuit breaker, current ratings from 1.5A to 125A, residual current ratings from 30mA to 500mA.

· Circuit breakers are classified into three levels based on their rated ultimate short-circuit breaking capacity (Icu): C Type (Basic), L Type (Standard), and M Type (Higher Breaking Capacity).

· Circuit breakers allow reverse feed connection.

· Circuit breakers can be installed vertically or horizontally on vertical mounting plates, or on horizontal mounting plates, and can also be mounted on DIN rails (CM5X-125).

· Circuit breakers have an isolating function, indicated by the symbol: 1X.

· Products comply with the following standards:

· IEC 60947-1 and GB/T 14048.1-2012 Low-voltage switchgear and controlgear - General rules

· IEC 60947-2 and GB/T 14048.2-2008 Low-voltage switchgear and controlgear - Circuit-breakers

· IEC 60947-4-1 and GB/T 14048.4-2010 Low-voltage switchgear and controlgear - Contactors and motor-starters - Electromechanical contactors and motor-starters (including motor protection devices)

Normal Service and Mounting Conditions

· Ambient air temperature: -5°C to +40°C;

· Altitude at installation site not exceeding 2000m;

· Relative humidity at the installation site does not exceed 50% at a maximum temperature of +40°C, and can be higher at lower temperatures, e.g., 90% at 20°C. Special measures should be taken for occasional condensation due to temperature changes;

· Pollution Degree 3;

· Circuit breakers meet GB/T 2423.10 test requirements, capable of withstanding mechanical vibration: 2Hz to 13.2Hz with displacement of ±1mm and 13.2Hz to 100Hz with acceleration of ±0.7g;

· Installation Category for the main circuit is III; for other auxiliary and control circuits, it is II;

· Circuit breakers are suitable for Electromagnetic Environment A;

· Tropical humid type (TH type) circuit breakers meet GB/T 2423.4 and GB/T 2423.18 test requirements, capable of withstanding the effects of humid air, salt mist, oil mist, and mold;

· Circuit breakers should be installed in locations free from explosion hazards, conductive dust, and substances sufficient to corrode metal or damage insulation;

· Circuit breakers should be installed in locations protected from rain and snow;

· Extended Service Conditions:

· Circuit breakers meet GB/T 2423.1 and GB/T 2423.2 test requirements; ambient air temperature can be as low as -25°C and as high as +70°C (derating required above +40°C, see technical data in this catalog);

· Circuit breakers meet GB/T 2423.4 test Db requirements (temperature +55°C, relative humidity 95%);

· Characteristics unaffected up to an altitude of 2500m (derating required above 2500m, see technical data in this catalog);

· Storage Conditions: Ambient air temperature: -25°C to +70°C.
