Delixi CDM3E-125M 3348 125A Shunt/electrically operated AC230V molded case circuit breaker
Brand:
Series:
CDM3E
Protection Type:
Power distribution protection, motor protection
How It Works:
electric
Frame Current:
125A
Tripping Mode:
Electronic
Protection Function:
LSI
Wiring Method:
Front panel wiring
Poles:
3P
Rated Voltage:
400/415VAC
Installation:
Fixed
Trip Unit:
Electronic release
Rated Current of Release:
125A
Breaking Capacity:
50KA
Model:
CDM3E-125M 3348 125A Shunt/electric operation AC230V
Order Number:
M3E125M1253348AP7
Description:
Delixi molded case circuit breaker CDM3E-125M 3348 125A shunt/electric operation AC230V, LSI, distribution protection, motor protection, 50KA, 125A, fixed, electric, 3P
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Delixi | |
| Series： | CDM3E | |
| Appendix： | Shunt release, auxiliary contact, alarm contact | |
| Protection Type： | Power distribution protection, motor protection | |
| How It Works： | electric | |
| Frame Current： | 125A | |
| Tripping Mode： | Electronic | |
| Protection Function： | LSI | |
| Wiring Method： | Front panel wiring | |
| Poles： | 3P | |
| Rated Voltage： | 400/415VAC | |
| Installation： | Fixed | |
| Trip Unit： | Electronic release | |
| Rated Current of Release： | 125A | |
| Breaking Capacity： | 50KA |
Products with the same attribute : 0
Show details
Series Overview
CDM3E Series Overview Outline - Compliant Standards
● GB/T 14048.1 General Rules
● IEC 60947-1 Low-voltage switchgear and controlgear - Part 1: General rules
● GB/T 14048.2 Circuit-breakers
● IEC 60947-2 Circuit-breakers - Pollution Degree
● CDM3E series products operate in an environment (industrial environment) defined by IEC 60947-1 and IEC 60664-1 standards, with a Pollution Degree of 3.
● According to Table H.1 of GB/T 14048.1-2012: Withstand capability in humid-heat environments at an altitude of 2000m with a rated impulse withstand voltage of 8kV.
● Ambient Air Temperature:
● Upper limit: +70°C, Lower limit: -40°C; 24-hour average temperature not exceeding +35°C. (Note: For use between -40°C to -25°C and +40°C to +70°C, refer to the derating factor table.)
● Storage temperature: -40°C to +70°C
● Altitude:
● Normal operating installation altitude does not exceed 2000m.
● If installation at altitudes exceeding 2000m is required, changes in dielectric strength and the factor of decreasing air temperature must be considered. Refer to the altitude derating factor table for use.
● Humidity:
● Under normal operating conditions:
● At an ambient air temperature of +40°C, the relative humidity of the atmosphere must not exceed 50%. At lower temperatures, higher relative humidity is permissible.
● The monthly average relative humidity of the most humid month is 90%.
● The impact of condensation on the product surface on product performance must be considered.
● Reliable Contact Position Indication with Isolation Function:
● CDM3E series Molded Case Circuit Breakers (MCCBs) comply with the isolation requirements defined in IEC 60947-2.
● The isolation position corresponds to the "0" (OFF) position.
● The operating handle can only indicate the "OFF" position when the contacts are physically open.
● The reliability of the contact position indication system cannot be altered by the rotary handle or the electrical operating mechanism.
● Protection Class (IP Rating):
● Breaker body: IP20 (excluding terminals).
Breaker installed in a switchgear cabinet:
● Breaker with rotary manual operator: IP40
● Breaker with electrical operating mechanism: IP40
