Delixi CDM3V-125BS/3300 125A Molded Case Circuit Breaker
Brand:
Series:
CDM3v
Protection Type:
Main body (with protection function)
How It Works:
Manual
Frame Current:
125A
Tripping Mode:
Thermal Magnetic
Protection Function:
LI
Wiring Method:
Front panel wiring
Poles:
3P
Rated Voltage:
400/415VAC
Installation:
Fixed
Trip Unit:
-
Rated Current of Release:
125A
Breaking Capacity:
35KA
Model:
CDM3V-125BS/3300 125A
Order Number:
M3V125BS1253300
Description:
Delixi Molded Case Circuit Breaker CDM3V-125BS/3300 125A,LI,35KA,125A,Fixed,Manual,3P
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Delixi | |
| Series： | CDM3v | |
| Appendix： | - | |
| Protection Type： | Main body (with protection function) | |
| How It Works： | Manual | |
| Frame Current： | 125A | |
| Tripping Mode： | Thermal Magnetic | |
| Protection Function： | LI | |
| Wiring Method： | Front panel wiring | |
| Poles： | 3P | |
| Rated Voltage： | 400/415VAC | |
| Installation： | Fixed | |
| Trip Unit： | - | |
| Rated Current of Release： | 125A | |
| Breaking Capacity： | 35KA |
Products with the same attribute : 0
Show details
Series Overview
Product Introduction
The CDM3v series Molded Case Circuit Breakers (hereinafter referred to as CDM3v) are mechanical switching devices capable of making, carrying, and breaking currents under normal circuit conditions, and also making, carrying for a specified time, and breaking currents under specified abnormal circuit conditions such as overload, short-circuit, and under-voltage (accessory function) in low-voltage distribution circuits. They provide protection for circuits and equipment. Widely applicable in low-voltage power consumption places such as power, construction, industry, and OEM.
● Frame Ratings: 63AF, 100AF, 125AF, 160AF, 250AF, 400AF, 630AF, 800AF, 1600AF
● Rated Operational Voltage (Ue): 400/415V, 500V, 690V
● Breaking Capacity: Covers common breaking capacities in the distribution field: 25kA, 35kA, 50kA, 70kA, 75kA
● Number of Poles: Includes 3-pole and 4-pole products
● Trip Unit Types: Magnetic-only, Thermomagnetic
● Mounting Methods: Fixed, Plug-in, Drawout
Compliance Standards
● Product Conforms to Standards:
● GB/T 14048.1 General rules
● GB/T 14048.2 Circuit-breakers
● IEC 60947-1 General rules
● IEC 60947-2 Circuit-breakers
● Extreme Environmental Usage Standards:
● IEC 60068-2-1 (Low temperature) / GB/T 2423.1
● IEC 60068-2-2 (High temperature) / GB/T 2423.2
● IEC 60068-2-30 (Damp heat, cyclic) / GB/T 2423.4
Protection Degree (IP Rating)
● The CDM3v body conforms to IP protection degree: IP30 (excluding terminal area).
● CDM3v breakers installed in switchgear cabinets:
● Breakers with toggle handle: IP40
● Breakers with rotary handle: IP40
● Breakers with motor operator: IP40
Operating Conditions
● Pollution Degree
● The operational pollution degree for CDM3v is Degree 3, suitable for environments (industrial environments) as defined by standards IEC 60947-1 and IEC 60664-1.
● Ambient Temperature
● Normal operating conditions: -5°C to +40°C; If the operating ambient temperature exceeds +40°C, refer to the temperature derating coefficient table for use.
● Storage temperature: -40°C to +70°C (If the storage temperature is lower than normal operating conditions, allow the product to stabilize at the operating temperature for at least 24 hours before use).
● Altitude
● Normal operating altitude: ≤ 2000m.
● If installation is required at altitudes exceeding 2000m, changes in dielectric strength and air cooling effects must be considered; refer to the altitude derating coefficient table for use.
● Humidity
● Normal operating humidity: At an ambient air temperature of +40°C, the relative humidity must not exceed 50%.
● At lower temperatures, higher relative humidity is permissible; for example, 90% at +20°C.
● Reliable Contact Position Indication with Isolation Function
● Complies with isolation requirements as defined in IEC standard GB/T 14048.2.
● The isolation position corresponds to the "0" (OFF) position.
● The operating handle can only indicate the "OFF" position when the contacts are physically open.
● The reliability of the contact position indication system is not affected by the use of a rotary handle or motor operator.
