Delixi CDM6I-100M/33002 20A Molded Case Circuit Breaker
Brand:
Series:
CDM6i
Protection Type:
Motor protection
How It Works:
Manual
Frame Current:
100A
Tripping Mode:
Thermal Magnetic
Protection Function:
LI
Wiring Method:
Front panel wiring
Poles:
3P
Rated Voltage:
400/415VAC
Installation:
Fixed
Trip Unit:
Compound release
Rated Current of Release:
20A
Breaking Capacity:
50KA
Model:
CDM6I-100M/33002 20A
Order Number:
M6I100M2033002
Description:
Delixi molded case circuit breaker CDM6I-100M/33002 20A,LI,motor protection,50KA,100A,fixed,manual,3P
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Delixi | |
| Series： | CDM6i | |
| Appendix： | - | |
| Protection Type： | Motor protection | |
| How It Works： | Manual | |
| Frame Current： | 100A | |
| Tripping Mode： | Thermal Magnetic | |
| Protection Function： | LI | |
| Wiring Method： | Front panel wiring | |
| Poles： | 3P | |
| Rated Voltage： | 400/415VAC | |
| Installation： | Fixed | |
| Trip Unit： | Compound release | |
| Rated Current of Release： | 20A | |
| Breaking Capacity： | 50KA |
Products with the same attribute : 0
Show details
Series Overview
Applicable Standards
- GB/T 14048.1 General rules
- GB/T 14048.2 Circuit-breakers
- IEC 60947-1 General rules
- IEC 60947-2 Circuit-breakers
Pollution Degree
- The CDM6i series products operate in environments defined as Pollution Degree 3 according to IEC 60947-1 and 60664-1 standards (industrial environments).
Resistance to Climatic Conditions
- Dry cold, dry heat, damp heat
Ambient Temperature
- Upper limit of surrounding air temperature: +70°C; Lower limit: -40°C; 24-hour average temperature not exceeding 35°C.
- (Note: For use within the range of -40°C to -25°C and +40°C to +70°C, please refer to the derating factor table.)
- Storage temperature: -40°C to +70°C.
Altitude
- Normal operating altitude: ≤ 2000m.
- If installation is required at altitudes exceeding 2000m, changes in dielectric strength and the decrease in air cooling capability must be considered. Refer to the altitude derating factor table for use.
Humidity
- Normal operating conditions require:
- Relative humidity of the atmosphere not exceeding 50% at a surrounding air temperature of +40°C. At lower temperatures, a higher relative humidity is permissible.
- The monthly average relative humidity of the wettest month is 90%.
- The impact of condensation forming on the product surface on product performance must be considered.
Reliable Contact Position Indication with Isolating Function
- CDM6i series molded case circuit breakers all comply with the definition of isolation specified in IEC standard 60947-2.
- The isolating position corresponds to the "0" (OFF) position.
- The operating handle can only indicate the "0" (OFF) position when the contacts are genuinely open.
- Operation via a rotary handle or electrical operating mechanism does not compromise the reliability of the contact position indication system.
- Through testing, the isolating function must ensure:
- Mechanical reliability of the contact position indication system.
- Absence of leakage current.
- Adequate impulse withstand voltage capability between terminals.
Degree of Protection (IP Code)
- Circuit breaker body: IP20.
- Circuit breaker installed in a switchgear cabinet:
- Circuit breaker with toggle handle: IP40.
- Circuit breaker with electrical operating mechanism: IP40.
