Hangshen HSM1-160/4200A 63A Molded Case Circuit Breaker

Brand:

Hangshen

Series:

HSM1

Protection Type:

Main body (with protection function)

How It Works:

Manual

Frame Current:

160A

Tripping Mode:

Electromagnetic

Protection Function:

Wiring Method:

Front panel wiring

Poles:

Rated Voltage:

400VAC

Installation:

Fixed

Trip Unit:

Instantaneous release

Rated Current of Release:

63A

Breaking Capacity:

50KA

Model:

HSM1-160/4200A 63A

Order Number:

Description:

Hangshen Molded Case Circuit Breaker HSM1-160/4200A 63A,I,50KA,160A,Fixed,Manual,4P

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Hangshen
Series：	HSM1
Appendix：	-
Protection Type：	Main body (with protection function)
How It Works：	Manual
Frame Current：	160A
Tripping Mode：	Electromagnetic
Protection Function：	I
Wiring Method：	Front panel wiring
Poles：	4P
Rated Voltage：	400VAC
Installation：	Fixed
Trip Unit：	Instantaneous release
Rated Current of Release：	63A
Breaking Capacity：	50KA

Products with the same attribute : 0

Show details

Series Overview

Application and Scope of Use

● The H5M1 series moulded case circuit breakers (hereinafter referred to as circuit breakers) are suitable for circuits with an AC 50Hz rated insulation voltage of 800V (HSM1-63 has a rated insulation voltage of 690V), a rated operational voltage up to 690V, and a rated current from 10A to 800A. They are used for distributing electrical energy and for infrequent switching operations under normal conditions. They also provide protection against overload, short-circuit, and undervoltage for lines and equipment.

● Circuit breakers with a rated frame current of 400A and below can also be used for the infrequent starting of squirrel cage motors and provide protection against motor overload, short-circuit, and undervoltage.

● This circuit breaker has an isolation function, denoted by the symbol HX_.

● The circuit breaker complies with standards such as IEC 60947-2 and GB/T 14048.2.

Normal Service and Mounting Conditions

● Ambient Air Temperature: -25°C to +70°C, with the average value over any 24-hour period not exceeding +35°C; Derating is required for ambient temperatures exceeding +40°C. Products suitable for temperatures as low as -40°C are available; please contact our company when ordering.

● Altitude: The altitude at the installation site should not exceed 2000m; Derating is required for installations above 2000m.

● Relative Humidity: The relative humidity of the air at the installation site should not exceed 50% at +40°C. Higher relative humidity is permissible at lower temperatures, for example, 95% at +20°C. Suitable measures should be taken for conditions where condensation or frost occurs.

● Installation Environment: The circuit breaker shall be installed in a medium without explosion hazard, free from gases or conductive dust sufficient to corrode metals or damage insulation, and free from rain and snow.

● Pollution Degree: Pollution Degree 3.

● Installation Category: The main circuit of the circuit breaker is Installation Category III. Other auxiliary and control circuits are Installation Category I.

● Mounting Orientation: The basic mounting orientation is vertical, but horizontal mounting is also permissible.
