Schneider NSX250F TM250D 4P4D (4P) AC220V Molded Case Circuit Breaker

Name: Schneider NSX250F TM250D 4P4D (4P) AC220V Molded Case Circuit Breaker
SKU: C25F4TM250M1

Brand:

Schneider

Series:

NSX (New)

Protection Type:

Power distribution protection

How It Works:

electric

Frame Current:

250A

Tripping Mode:

Thermal Magnetic

Protection Function:

Wiring Method:

Front panel wiring

Poles:

Rated Voltage:

380/415VAC

Installation:

Fixed

Trip Unit:

TMD

Rated Current of Release:

250A

Breaking Capacity:

36KA

Model:

NSX250F TM250D 4P4D (4P) Electric AC220V Fixed front wiring

Order Number:

C25F4TM250M1

Description:

Schneider Molded Case Circuit Breaker NSX250F TM250D 4P4D (4P) Electric AC220V Fixed Front Wiring, LI, Power Distribution Protection, 36KA, 250A, Fixed, Electric, 4P

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Schneider
Series：	NSX (New)
Appendix：	-
Protection Type：	Power distribution protection
How It Works：	electric
Frame Current：	250A
Tripping Mode：	Thermal Magnetic
Protection Function：	LI
Wiring Method：	Front panel wiring
Poles：	4P
Rated Voltage：	380/415VAC
Installation：	Fixed
Trip Unit：	TMD
Rated Current of Release：	250A
Breaking Capacity：	36KA

Products with the same attribute : 0

Show details

Series Overview

ComPacT NSX, Extreme Innovation and Efficiency

● ComPacT NSX circuit breakers utilize Schneider Electric's unique double-break technology, significantly reducing the impact of short circuits on the power distribution system.

● Currently optimized with high-level breaking capacity, excellent selectivity, and cascading, the ComPacT NSX series offers more advanced features and a more user-friendly design, simplifying installation and operation.

New Feature Design

● Schneider Electric's signature green design will cover the entire ComPacT NSX series.

● Expected to reduce wiring time for panel builders by up to 40%.

● A new ergonomic front panel design enables easier installation.

● Ensures all accessories are correctly positioned and allows easy verification of coil ratings.

● A new ergonomic handle design facilitates easier manual operation of the circuit breaker.

Wireless Indication of Circuit Breaker Status

● Plug-and-play technology ensures clear connection status.

● Positioned in the same location as wired auxiliary contacts, its LED flashes a signal upon tripping, providing direct indication.

● If you are not near the circuit breaker, your ComPacT NSX will immediately send you a message via EcoStruxure-enabled professional devices.

● Wireless auxiliary contacts accelerate overall wiring time: Communication regarding the circuit breaker status can be easily achieved through our wireless devices.

● The communication architecture is fully compatible with the EcoStruxure Power system for any application.

The Smallest Size in the Series

● ComPacT NSX 100m/160m is not only the smallest product in the series but also incorporates new features and innovative technologies.

● Saves up to 40% space when using integrated earth leakage protection.

● Saves up to 40% installation and wiring time when using EverLink connectors, built-in DIN rails, and spring clamp terminal accessories.

● Schneider Electric's online tools – EcoStruxure Customer Lifecycle Software, such as EcoStruxure Power Design - Ecodial, can help you easily select, configure, and commission our products.

Integrated Earth Leakage Protection

● Replaceable trip units easily add earth leakage protection to circuit breakers that previously lacked it.

● Simple, easy to use, convenient, and reliable, while ensuring the same frame size is maintained, eliminating the need to replace distribution cabinets.

● Saves up to 40% space when using integrated earth leakage protection in electronic trip units.

● Provides standard protection for distribution cables.

● Part of the EcoStruxure Power architecture, featuring digital communication capabilities and data management (settings, measurements, pre-alarms, trip history, and test records).

Double-Break Technology

● Although ComPacT NSX 100m/160m is the smallest product in the ComPacT NSX series, it still incorporates all the innovative technologies of previous generations, specifically including double-break technology. Schneider Electric has successfully introduced this technology, which effectively limits fault current, offering significant benefits for this equipment, particularly cables.

Reducing the Impact of Short Circuits to Extend Your Equipment's Lifespan:

● Extends the service life of all equipment downstream in the electrical network.

● Simultaneously provides excellent selectivity and cascading.

Connectivity: From Troubleshooting to Predictive Maintenance

● As Schneider Electric's IoT-enabled connected power architecture, EcoStruxure Power makes maintenance more efficient and reduces the probability and duration of power outages. ComPacT NSX circuit breakers play a key role in the EcoStruxure architecture, acting as monitoring experts for the power system and providing data support for the digital architecture and monitoring software.

New Packaging

● ComPacT NSX series products feature plastic-free packaging: reducing our carbon footprint and waste in production workshops.

● All packaging includes simplified instructions.

● 100% recyclable cardboard boxes.

● Scan the QR code to access electronic documentation.

● This product complies with REACH and RoHS standards.
