Schneider JGA36200 Molded Case Circuit Breaker

Name: Schneider JGA36200 Molded Case Circuit Breaker
SKU: JGA36200

Brand:

Schneider

Series:

PowerPact

Protection Type:

Power distribution protection

How It Works:

Manual

Frame Current:

250A

Tripping Mode:

Thermal Magnetic

Protection Function:

Wiring Method:

I-Line Wiring

Poles:

Rated Voltage:

380/415VAC

Installation:

Fixed

Trip Unit:

Rated Current of Release:

200A

Breaking Capacity:

35KA

Model:

JGA36200

Order Number:

JGA36200

Description:

Schneider molded case circuit breaker JGA36200,LI,distribution protection,35KA,250A,fixed,manual,3P

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Schneider
Series：	PowerPact
Appendix：	-
Protection Type：	Power distribution protection
How It Works：	Manual
Frame Current：	250A
Tripping Mode：	Thermal Magnetic
Protection Function：	LI
Wiring Method：	I-Line Wiring
Poles：	3P
Rated Voltage：	380/415VAC
Installation：	Fixed
Trip Unit：	TM
Rated Current of Release：	200A
Breaking Capacity：	35KA

Products with the same attribute : 0

Show details

Series Overview

PowerPct Series Molded Case Circuit Breakers (MCCBs)

The entire PowerPact series of MCCBs meets both CCC certification and UL ABD certification.

*The comprehensive product range offers diverse options, catering to applications requiring advanced features like power metering, as well as cost-effective solutions with basic protection.

All PowerPact products support various installation and connection methods. Compact dimensions and modular accessories provide convenience and cost savings for OEM customers during installation and upgrades.

Frame Sizes

● B-frame: 125A (Current range: 15~125A)

● H-frame: 150A (Current range: 15A~150A)

● J-frame: 250A (Current range: 175A~250A)

● L-frame: 600A (Current range: 400A-600A)

Rated Operational Voltage

● Entire series rated operational voltage: 690V

● Breaking capacity up to 100kA (L-frame at 480V AC)

● B-frame: D (18kA), G (32kA), J (82kA)

● H/J-frame: D (18kA), G (35kA), L (65kA), L (100kA)

● L-frame: G (38kA), J (38kA), L (100kA)

Number of Poles

● B-frame: 1P/2P/3P/4P

● H-frame: 2P/3P

● J-frame: 2P/3P

● L-frame: 3P/4P

Trip Units

● B-frame: Thermomagnetic trip unit

● H/J-frame: Thermomagnetic trip unit / Electronic trip unit

● L-frame: Electronic trip unit

Protection Types

● B-frame: Distribution protection

● L-frame: Distribution protection, Motor protection

Certifications and Standards

● UL 489

● IEC 60947-2

● CCC

● Multiple Marine Classification Society Certifications: ABS, BV, CCS, DNV/GL, LR, LRS, NK, RINA, RMRS

Diverse Connections and Installation

■ The entire PowerPact series supports multiple connection methods, including standard aluminum cable connectors, multi-cable connectors, lug connections, plus PowerPact-specific I-Line connections and innovative EverLink connections.

■ I-Line

● PowerPact H/J/L-frame breakers support I-Line connection. Plug-in wiring is simple and convenient, requiring no additional termination. The connection between breaker terminals and busbars is fuller and more secure.

● I-Line breakers are integral units; their terminals cannot be removed or replaced.

● I-Line serves as the line-side connection method; load-side connections can be cable connectors or lugs.

■ EverLink (B-frame only)

● PowerPact B-frame innovatively uses EverLink cable connection, utilizing creep compensation to maintain precise and durable tightening torque, ensuring reliable termination.

● EverLink connectors accept bare cables directly, saving installation time and space.

● EverLink connectors with auxiliary contact holes can supply power to electrical accessories or enable electrical measurements.

Installation

● The entire PowerPact series can be installed vertically, horizontally, or flat without affecting performance.

● PowerPact B-frame supports backplate mounting, dual rail mounting, and DIN rail mounting.

PowerPact B-frame MCCB General Characteristics

Applications

● Industrial Control Panels: Can be used as main switches, branch circuit protection, or motor circuit protection devices. Complies with IEC 60947-2 and UL 489/CSA C22.2 No. 5. Provides short-circuit and overload protection. Suitable for various switchgear assemblies.

● Power Distribution System Protection: Used in building power distribution systems for branch or main feeder protection. Complies with international standards, provides short-circuit and overload protection. Multiple installation methods and accessories offer comprehensive protection.

Thermomagnetic Trip Unit

● PowerPact B-frame thermomagnetic trip units use dual-sensor technology, providing both thermal and magnetic protection.

● Protection Type: Thermomagnetic TM for distribution systems.

Installation Methods

● PowerPact B-frame MCCBs can be installed horizontally, vertically, or flat without affecting performance.

● Can be directly mounted on 35mm DIN rails.

● Supports backplate mounting. Includes two sets of M4 screws, washers, and nuts.

● Mounting screws insert into molded mounting holes on the breaker housing and secure to the rail or backplate.

PowerPact H-frame, J-frame, L-frame MCCB General Characteristics

Vibration

● PowerPact H, J, and L-frame breakers pass seismic tests required by UL ABD SA and SB (Veritas*, Lloyd*, etc.). They also meet IEC 60068-2-6 seismic requirements:

● 2.0 to 2.5Hz: Amplitude +/- 1.6mm

● 25.0 to 100Hz: Acceleration +/- 4.0g

Electromagnetic Interference (EMI)

● H, J, L-frame breakers withstand interference from:

● Overvoltages caused by circuit switching.

● Overvoltages from atmospheric disturbances or aging power systems (e.g., lighting faults).

● Radio frequency interference (radio, walkie-talkies, radar, etc.).

● Direct electrostatic discharge by users.

● Successfully passed EMC tests defined by:

● IEC/EN 60947-2: Annex F, Annex B

● IEC/EN 61000-4-2 (ESD)

● IEC/EN 61000-4-3 (Radiated RF)

● IEC/EN 61000-4-4 (EFT/Burst)

● IEC/EN 61000-4-5 (Surge)

● IEC/EN 61000-4-6 (Conducted RF)

● CISPR 11 (Emissions)

Damp Heat

● H, J, L-frame breakers pass tests defined for extreme atmospheric conditions (dry cold/dry heat):

● IEC 60068-2-1: Dry Cold (-55°C)

● IEC 60068-2-2: Dry Heat (+85°C)

● Damp Heat:

● IEC 60068-2-30: Damp Heat (+55°C, 95% RH)

● IEC 60068-2-52 Severity Level 2: Salt Mist

Available Trip Units for H, J, L-frame

● H, J, and L-frame breakers offer interchangeable thermomagnetic and electronic trip units. H and J-frames can use thermomagnetic units with independent thermal and magnetic protection per pole.

● Micrologic electronic trip units provide intelligent operation for precise settings. They use dual-sensor technology: iron-core sensors for power supply, air-core sensors for measurement. Independent sensors ensure accuracy by separating supply and detection.

● "Ready" LED: Located on the white front panel of the trip unit. The green LED flashes when the trip unit is ready for protection, indicating proper operation without test tools.

● Micrologic 5/6 trip units feature dual adjustable controls:

● Knob for coarse adjustment (max value).

● Buttons for fine parameter adjustment (increments of 1A or fractions). Adjusted values display clearly.
