Schneider NSX100F TM50D 3P3D (3P) Molded Case Circuit Breaker
Brand:
Series:
NSX
Protection Type:
Power distribution protection
How It Works:
Manual
Frame Current:
100A
Tripping Mode:
Thermal Magnetic
Protection Function:
LI
Wiring Method:
Front panel wiring
Poles:
3P
Rated Voltage:
380/415VAC
Installation:
Fixed
Trip Unit:
TMD
Rated Current of Release:
50A
Breaking Capacity:
36KA
Model:
NSX100F TM50D 3P3D (3P) Fixed front wiring
Order Number:
LV429633
Description:
Schneider Molded Case Circuit Breaker NSX100F TM50D 3P3D (3P) Fixed front wiring, LI, distribution protection, 36KA, 100A, fixed, manual, 3P
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Schneider | |
| Series： | NSX | |
| Appendix： | - | |
| Protection Type： | Power distribution protection | |
| How It Works： | Manual | |
| Frame Current： | 100A | |
| Tripping Mode： | Thermal Magnetic | |
| Protection Function： | LI | |
| Wiring Method： | Front panel wiring | |
| Poles： | 3P | |
| Rated Voltage： | 380/415VAC | |
| Installation： | Fixed | |
| Trip Unit： | TMD | |
| Rated Current of Release： | 50A | |
| Breaking Capacity： | 36KA |
Products with the same attribute : 0
Show details
Series Overview
N6X, Precision and Efficiency in Modular Design
- Compact NSX circuit breakers utilize Schneider Electric's unique double-break technology, which significantly reduces the impact of short circuits on the distribution system.
- Compact NGX series is optimized through high breaking capacity, excellent selectivity, and coordination. It offers advanced features and a more user-friendly design, making installation and operation simpler.
Precision Design Features
- Schneider Electric's distinctive design covers the entire Compact NSX series.
- Expected to reduce overall operating time by up to 50%.
- Ergonomic, fully shielded terminal design facilitates easier installation.
- Ensures all accessories are correctly positioned, allowing easy verification of trip unit settings.
- Ergonomic handle design makes manual operation of the circuit breaker easier.
- Ready-to-Use technology ensures accurate connection status.
- Positioned in the same location as wired auxiliary contacts, its LED flashes a signal during tripping, providing you with immediate information.
- If you are not near the circuit breaker, your Compact NSX will immediately send you information via connected professional devices.
- Wireless auxiliary contacts accelerate overall operating time: Communication about the circuit breaker status can be easily achieved via our wireless devices.
- Ensures full compatibility with IT systems, suitable for any application.
Minimal Dimensions Required
- Compact NSX 100m/160m is not only the smallest product in the series but also incorporates precise functions and innovative technology.
- Saves up to 50% space when using integrated earth leakage protection.
- Using Link tags, built-in DIN rails, and clip-on accessories saves up to 50% on installation and operating time.
- Schneider Electric's online tools – customer lifecycle software like EcoStruxure™ From Design to Operation – help you easily select, configure, and test our products.
Integrated Earth Leakage Protection
- Replaceable trip units easily add earth leakage protection to circuit breakers that originally lacked it.
- Simple, convenient, reliable, and ensures the same frame size is used, eliminating the need for panel replacement.
- Saves up to 50% space when using integrated earth leakage protection in the electronic trip unit.
- Complies with standard protection for distribution cables.
- Part of the renowned EcoStruxure™ Power architecture, utilizing digital communication capabilities and data management (settings, measurements, pre-alarms, usage, and test records).
Compact NSX 160N/160H is the smallest product in the Compact NSX series. Yet it retains all the innovative technologies of the previous generation. It notably includes double-break technology, a highly effective fault current limiting technology successfully introduced by Schneider Electric. This innovation offers significant benefits for the equipment, especially cables.
- Reduces the impact of short circuits, extending the service life of your equipment.
- Extends the service life of all equipment downstream in the electrical network.
- Simultaneously provides excellent selectivity and coordination.
Interconnectivity: From Troubleshooting to Predictive Maintenance
- As part of Schneider Electric's connected power architecture, EcoStruxure™ makes maintenance more efficient and reduces the frequency and duration of outages. Compact NSX circuit breakers play a key role in the EcoStruxure™ architecture, acting as monitoring experts for the power system and providing data support for the digital architecture and monitoring software.
Applications, Analytics, and Services
- Actionable predictive maintenance information effectively serves your customers, protects your reputation, and minimizes financial impact.
- Remote Control
- Optimizes maintenance activities to reduce downtime, energy consumption, and maintenance costs, while improving site planning and offering additional features.
- Connected Products
- Our medium and low voltage products are all IoT-enabled and fully compatible with EcoStruxure™.
- Compliance with Standards
- Compact NSX circuit breakers and disconnectors comply with the following standards:
- International Standards:
- IEC 60947-1: General Rules
- IEC 60947-2: Circuit Breakers
- IEC 60947-3: Switches, Disconnectors, Switch-Disconnectors and Fuse-Combination Units
- IEC 60947-4-1: Contactors and Motor-Starters
- IEC 60947-5-1 and below: Control Circuit Devices and Switching Elements
- European Standards (EN 60947-1, EN 60947-2, EN 60947-3, EN 60947-4-1, EN 60947-5-1)
- China Compulsory Certification (CCC)
- GOST-R (Russia)
- National Certifications (French UTE, German VDE, Italian CEI, etc.) and norms from organizations like NFPA for machine protection in buildings.
Pollution Degree
- Compact NSX circuit breakers can operate in environments defined as Pollution Degree 3 by standards IEC 60947-1 and IEC 60664-1 (Industrial environments).
Climatic Capability
- Compact NSX is designed for the most severe atmospheric conditions: clean and dry.
- IEC 60068-2-1: Dry cold test at -55°C.
- IEC 60068-2-2: Dry heat test at +70°C.
- Damp Heat Tests (Cyclic Conditions):
- IEC 60068-2-30: Damp heat, cyclic (55°C, relative humidity: 95%).
- IEC 60068-2-52: Salt mist, severity 3.
- Environmental Protection
- Compact NSX considers Schneider Electric's environmental commitments, complying with the European environmental declaration for electronic products ECMA-370.
- All Compact NSX production plants comply with the ISO 14001 standard.
- Each plant has detailed production monitoring procedures, fully preventing pollution and reducing consumption of natural resources.
- Ambient Temperature
- Compact NSX circuit breakers can operate from -25°C to +70°C. Derating should be considered for temperatures above 40°C (or 60°C for motor protection).
- Compact NSX circuit breakers can operate long-term under normal environmental and operating temperature conditions, and also operate normally within an ambient temperature range of -25°C to +70°C.
- Storage temperature is -50°C to +85°C.
- [1] For Compact NGX: Micrologic control units with LCD screen and Micrologic 4 are -40°C.
- Electromagnetic Compatibility (EMC)
- Compact NSX circuit breakers are protected against:
- Overvoltages caused by switching operations (e.g., lighting circuit switching).
- Overvoltages caused by atmospheric disturbances.
- Radiofrequency interference from equipment.
- Electrostatic discharges generated by users.
- Compact NSX circuit breaker immunity complies with the following standards:
- IEC/EN 60947-2: Low-voltage switchgear and controlgear - Part 2: Circuit-breakers.
- Annex F: Immunity tests for circuit-breakers with electronic overcurrent protection.
- Annex G: Immunity tests for circuit-breakers with residual current protection.
- IEC/EN 61000-4-2: Electrostatic discharge immunity test.
- IEC/EN 61000-4-4: Electrical fast transient/burst immunity test.
- IEC/EN 61000-4-5: Surge immunity test.
- IEC/EN 61000-4-6: Immunity to conducted disturbances, induced by radio-frequency fields.
- IEC/EN 61000-4-8: Power frequency magnetic field immunity test.
- IEC/EN 61000-4-11: Voltage dips, short interruptions and voltage variations immunity tests.
- CISPR 11: Industrial, scientific and medical (ISM) radio-frequency equipment - Electromagnetic disturbance characteristics - Limits and methods of measurement.
- IEC/EN 60947-2: Low-voltage switchgear and controlgear - Part 2: Circuit-breakers.
Reliable Isolating Contacts
- All Compact NSX circuit breakers comply with the definition of isolation in IEC standard 60947-3:
- The isolation position corresponds to the OFF (O) position.
- The operating handle can only indicate the "OFF" position when the contacts are truly open.
- Padlocks can only be fitted when the contacts are open.
- The reliability of the contact position indication system is not altered by rotary handles or motorized operating mechanisms [*].
- Tested isolation function must guarantee:
- Mechanical reliability of the contact position indication system.
- No leakage current.
- A certain overvoltage withstand capability between incoming and outgoing terminals.
- Isolation function cannot be guaranteed if the contacts are displaced.
- Accurate isolation is only ensured when in the OFF position.
Installation in Type-Tested Assemblies (TTA)
- All Compact NGX circuit breakers are insulated on the front for Type 1. They can be installed in Type 1 assemblies (per standards IEC 61140 and IEC 60439-1) without reducing the insulation class of the assembly. This characteristic also applies when the circuit breaker is equipped with a rotary handle or motorized operating mechanism [*].
Degree of Protection (IP Code)
- Complies with IEC 60529 (IP Code) and IEC 62262 (IK Code for resistance to external mechanical impacts).
- Circuit Breaker with Terminal Covers:
- Circuit breaker with toggle handle: IP40 IK07
- Circuit breaker with standard direct rotary handle (VDE standard): IP40 IK07
- Circuit Breaker Installed in an Assembly:
- Circuit breaker with toggle handle: IP40 IK07
- Circuit breaker with direct rotary handle:
- Standard/VDE: IP40 IK07
- CCM: IP43 IK07
- CNOMO: IP54 IK08
- Circuit breaker with extended rotary handle: IP55 IK08
- Circuit breaker with motorized operating mechanism [*]: IP40 IK07
- [*] Not applicable to universal motorized operating mechanisms.
