Siemens 3VA2 M630 R630 ETU550 F/3P Molded Case Circuit Breaker
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | 3VA2 | |
| Appendix： | - | |
| Protection Type： | Power distribution protection | |
| How It Works： | Manual | |
| Frame Current： | 630A | |
| Tripping Mode： | Electronic | |
| Protection Function： | LSI | |
| Wiring Method： | Front panel wiring | |
| Poles： | 3P | |
| Rated Voltage： | 380-415VAC | |
| Installation： | Fixed | |
| Trip Unit： | ETU550 | |
| Rated Current of Release： | 630A | |
| Breaking Capacity： | 55KA |
Series Overview
Frame Sizes
The complete 3VA portfolio comprises two different molded case circuit breaker series with five different rated operational currents (frame sizes). The new 3VA series molded case circuit breakers set new standards in terms of flexibility and diversity of modular accessories. Standard accessories suitable for the various 3VA frame sizes help reduce costs and save time. The 3VA1 molded case circuit breaker is available in 1-pole to 4-pole versions; the 100A breaker is available in 3-pole and 4-pole versions. The 3VA2 molded case circuit breaker is available in 3-pole and 4-pole versions. Depending on the series and frame size, the breakers cover rated operational currents from 16 to 630 A and rated voltages up to 690 V.
3VA2 Molded Case Circuit Breaker
The 3VA2 molded case circuit breaker reliably meets all requirements for line protection, generator protection, motor protection, and motor starter protection. This series is designed for applications with higher demands:
Features
The most important features of the 3VA2 series:
Compact Dimensions with Extended Functionality
In addition to its extended performance, the 3VA2 molded case circuit breaker's compact design is perfectly realized not only in the fixed-mounted version but also in the plug-in and withdrawable versions. A cover plate dimension of 70 mm for panel cutouts and the full selection of breaking capacities from 55 kA to 150 kA at 415 V AC provide the necessary planning flexibility. Despite the compact construction of the circuit breaker, the following advantages remain:
Selective Contact System
Due to its contact system, the 3VA2 molded case circuit breaker is designed for fast selective tripping performance. The selective contact system ensures the following functions:
Electronic Trip Units (ETUs)
The 3VA2 current transformers include an internally supplied iron-core transformer and a Rogowski coil for precise current measurement. Each transformer is optimized for its specific task. Due to the high accuracy of current measurement, the 3VA2 molded case circuit breaker is suitable for power/energy measurement. Furthermore, ground fault current monitoring is precisely adjustable. The electronic trip units (ETUs) provide the following protection functions:
Energy Management and Communication
The electronic trip units (ETUs) provide the following energy management and communication functions:
