Siemens 3VM1 N160 R25 TM220 F/4P Molded Case Circuit Breaker
Brand:
Series:
3VM1
Protection Type:
Power distribution protection
How It Works:
Manual
Frame Current:
160A
Tripping Mode:
Thermal Magnetic
Protection Function:
LI
Wiring Method:
Front panel wiring
Poles:
4P
Rated Voltage:
415VAC
Installation:
Fixed
Trip Unit:
TM220
Rated Current of Release:
25A
Breaking Capacity:
25KA
Model:
3VM1 N160 R25 TM220 F/4P
Order Number:
3VM11253EE420AA0
Description:
Siemens Molded Case Circuit Breaker 3VM1 N160 R25 TM220 F/4P,LI,Distribution Protection,25KA,160A,Fixed,Manual,4P
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | 3VM1 | |
| Appendix： | - | |
| Protection Type： | Power distribution protection | |
| How It Works： | Manual | |
| Frame Current： | 160A | |
| Tripping Mode： | Thermal Magnetic | |
| Protection Function： | LI | |
| Wiring Method： | Front panel wiring | |
| Poles： | 4P | |
| Rated Voltage： | 415VAC | |
| Installation： | Fixed | |
| Trip Unit： | TM220 | |
| Rated Current of Release： | 25A | |
| Breaking Capacity： | 25KA |
Products with the same attribute : 0
Show details
Series Overview
3VM Series Molded Case Circuit Breakers - Outline
Specifications
- 3VM Molded Case Circuit Breakers are an integral part of the Siemens power distribution system, providing protection for people and property.
- The new 3VM Molded Case Circuit Breakers set new standards in modularity for both internal and external accessories. Modular accessories and components fit all frame sizes, enabling fast installation, saving time, and reducing costs.
- The new molded case circuit breakers are available in 3-pole and 4-pole versions (100A, 160A, 250A, 400A, 630A).
- Depending on the specific series and frame size, the circuit breakers have rated operational currents ranging from 16A to 630A and rated voltages up to 500V.
3VM Molded Case Circuit Breakers
The new 3VM Molded Case Circuit Breakers reliably perform all tasks required for line protection.
Features
Key features of the 3VM series:
● Compact design
● Depending on frame size: 3-pole to 4-pole
● Depending on frame size: Breaking capacity of 16kA...55kA at 415V for 3-pole or 4-pole circuit breakers
● Fixed or plug-in versions
● Thermal-magnetic release
● AC/DC applications
● Derating not required below 50°C
● Modular and easy-to-install internal accessories with different functions
● Full range of internal accessories are universal
Compact Design
● Thanks to an installation depth of 70mm and a cover height of 45mm, the 3VM molded case circuit breakers in frame sizes 100A, 160A, and 250A are ideal for cable and line protection, especially in the field of electrical installation. For these applications, a wide range of accessories are also available, such as adapters for mounting on standard rails and Residual Current Devices (RCD110 and RCD210) that can be mounted on the side.
Thermal-Magnetic Release
● The thermal-magnetic release is the basic release unit, providing overload and short-circuit protection. It is suitable for three-phase AC grids, 400 Hz applications, and DC applications.
