TGM1N-125M/2300C 63A Molded Case Circuit Breaker
Brand:
Series:
TGM1N
Protection Type:
Main body (with protection function)
How It Works:
Manual
Frame Current:
125A
Tripping Mode:
Electromagnetic
Protection Function:
I
Wiring Method:
Front panel wiring
Poles:
2P
Rated Voltage:
230VAC
Installation:
Fixed
Trip Unit:
Instantaneous release
Rated Current of Release:
63A
Breaking Capacity:
35KA
Model:
TGM1N-125M/2300C 63A(Xiangyun 3.0)
Order Number:
ICX-6989936-700949
Description:
TENGEN Molded Case Circuit Breaker TGM1N-125M/2300C 63A,I,35KA,125A,Fixed,Manual,2P
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | TENGEN | |
| Series： | TGM1N | |
| Appendix： | - | |
| Protection Type： | Main body (with protection function) | |
| How It Works： | Manual | |
| Frame Current： | 125A | |
| Tripping Mode： | Electromagnetic | |
| Protection Function： | I | |
| Wiring Method： | Front panel wiring | |
| Poles： | 2P | |
| Rated Voltage： | 230VAC | |
| Installation： | Fixed | |
| Trip Unit： | Instantaneous release | |
| Rated Current of Release： | 63A | |
| Breaking Capacity： | 35KA |
Products with the same attribute : 0
Show details
Series Overview
TGMIN Series Molded Case Circuit Breakers Overview
- TGMIN series molded case circuit breakers are newly developed utilizing an advanced international technology platform. These products are suitable for providing distribution protection in circuits with AC 50/60Hz and rated operational voltage up to 690V. They can also be used for infrequent switching of circuits and infrequent starting of motors. Featuring an exquisite appearance, compact size, convenient maintenance, and superior performance, their excellent performance and high cost-effectiveness make them a comprehensive replacement for the MI series products available on the market.
- This series of circuit breakers incorporates overload and short-circuit protection devices.
- This series of circuit breakers can be installed vertically (upright) or horizontally (sideways).
- They possess an isolation function, indicated by the symbol:
- Circuit breakers comply with the following standards:
- IEC 60947-1 and GB/T 14048.1 "Low-voltage switchgear and controlgear - Part 1: General rules".
- IEC 60947-2 and GB/T 14048.2 "Low-voltage switchgear and controlgear - Part 2: Circuit-breakers".
- Product Certifications: CCC, CB, CE.
Normal Operating and Installation Conditions
- Ambient Temperature
- Normal operating temperature: -5°C to +40°C, extreme operating temperature: -40°C to +70°C.
- Derating is required according to the catalog specifications at temperatures below -5°C or above +40°C.
- Installation Category
- Main circuit: III, Other auxiliary circuits: II.
- Pollution Degree
- Degree 3.
- Altitude
- 2000 meters. Derating is required according to the catalog specifications for altitudes exceeding 2000 meters.
- Atmospheric Conditions
- Relative humidity not exceeding 50% at an ambient temperature of +40°C;
- Higher relative humidity is permissible at lower temperatures, e.g., 90% at 20°C. Special measures must be taken against condensation caused by temperature variations.
- Shock and Vibration
- The circuit breakers meet the requirements of GB/T 2423.10 and can withstand mechanical vibration with a frequency of 2Hz to 13.2Hz and displacement of ±1mm, and a frequency of 13.2Hz to 100Hz with an acceleration of ±0.7g.
