Schneider GV2-RT04 Motor Protection Circuit
Brand:
Series:
GV2
Application:
Thermal magnetic protection
Control Type:
Toggle control
Setting Current Range:
0.4-0.63A
Rated Power:
0.12-0.18KW
Auxiliary Contacts:
-
Wiring Method:
Screw terminals
Poles:
3P
Rated Voltage:
400/415VAC
Breaking Capacity:
100KA
Model:
GV2-RT04
Order Number:
GV2RT04
Description:
Schneider GV2-RT04, 0.12-0.18KW, breaking capacity 100KA, toggle control, thermal magnetic protection, 400/415VAC, screw terminal, pole number 3P
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Schneider | |
| Series： | GV2 | |
| Application： | Thermal magnetic protection | |
| Control Type： | Toggle control | |
| Setting Current Range： | 0.4-0.63A | |
| Rated Power： | 0.12-0.18KW | |
| Auxiliary Contacts： | - | |
| Wiring Method： | Screw terminals | |
| Poles： | 3P | |
| Rated Voltage： | 400/415VAC | |
| Breaking Capacity： | 100KA |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Introduction
- GV2 ME, GV2 P, GV3 ME, GV3 P motor circuit breakers are 3 - pole thermal circuit breakers, designed for the control and protection of motors, and comply with IEC 60947 - 2 and IEC 60947 - 4 - 1 standards.
Wiring
- GV2 ME and GV2 P circuit breakers adopt a connection design with screw - clamp terminals.
- GV2 ME circuit breakers can be connected with ring - type terminal lugs or spring - type terminal lugs.
- Spring - type terminal connections ensure safe, durable, and reliable clamping, and can resist harsh environments, vibrations, and impacts. They are especially effective when using flexible wires without ferrules. Each connection can connect two independent conductors.
Operation
- When the motor circuit breaker is used on its own, local manual control is adopted. When the motor circuit breaker is connected with a contactor, remote automatic control is adopted.
Motor and Personnel Protection
- Motor protection is provided by the thermal protection element in the motor circuit breaker.
- The electromagnetic element (short - circuit protection) has a non - adjustable tripping threshold, equivalent to 13 times the maximum rated current of the thermal circuit breaker.
- The thermal element (overload protection) includes automatic compensation for ambient temperature changes.
- The rated operating current of the motor is indicated by the setting knob 4.
- Personnel protection is also provided. All live components have been protected and cannot be directly touched by fingers from the front panel.
- Due to the addition of under - voltage tripping, the circuit breaker can be opened under under - voltage conditions. In this way, when the normal voltage is restored, the sudden start of the machine can be avoided, because to restart the motor, the “start button” must be pressed.
- After adding the separate tripping device, the opening of the thermal element can be controlled remotely.
- The controllers of open - mounted and enclosed motor circuit breakers can be locked in the stop position “O” with 4 padlocks.
- Because these circuit breakers have isolation functions, in the open position, an appropriate insulation distance will be left, and the actual position of the moving contact is indicated by the position indicator of the controller.
Features
- Due to their universal installation methods, these motor circuit breakers can be easily installed on any equipment: fixed with screws or clamped and installed on symmetrical, asymmetrical, or combined rails.
