Siemens 3RV6421-4BA10 14-20A 325A Motor Protection Circuit

Name: Siemens 3RV6421-4BA10 14-20A 325A Motor Protection Circuit
SKU: 3RV64214BA10

Brand:

Siemens

Series:

3RV6

Application:

Transformer protection

Control Type:

Knob control

Setting Current Range:

14-20A

Rated Power:

Auxiliary Contacts:

Wiring Method:

Screw terminals

Poles:

Rated Voltage:

400VAC

Breaking Capacity:

55KA

Model:

3RV6421-4BA10 14-20A 325A

Order Number:

3RV64214BA10

Description:

Siemens 3RV6421-4BA10 14-20A 325A, breaking capacity 55KA, knob control, transformer protection, 400VAC, screw terminal, number of poles 3P

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Siemens
Series：	3RV6
Application：	Transformer protection
Control Type：	Knob control
Setting Current Range：	14-20A
Rated Power：	-
Auxiliary Contacts：	-
Wiring Method：	Screw terminals
Poles：	3P
Rated Voltage：	400VAC
Breaking Capacity：	55KA

Products with the same attribute : 0

Show details

Series Overview

3RV6/3RV5 circuit breakers are compact - type motor starting protection circuit breakers. They can be used for the switching on/off and protection of three - phase induction motors (with a maximum power of 45kW at an AC voltage of 400V) and other loads (with a maximum rated current of up to 100A).

Applications

Operating Conditions

3RV6/3RV5 circuit breakers are suitable for any climate and are applied in the normal operating environment of enclosed spaces (such as dust - free, free of corrosive gases or harmful gases). When installed in dusty and humid places, appropriate protective covers need to be equipped.
3RV6/3RV5 circuit breakers can have wires connected from the top or the bottom.
For the ambient temperature allowed by the circuit breakers, the maximum breaking capacity, the tripping action current, and other conditions, refer to the specific technical data and tripping characteristic curves in this chapter.
3RV6/3RV5 circuit breakers can be used in IT systems (IT networks), but the different short - circuit breaking capacities in IT systems should be taken into account.
Even for motors with the same rated power, due to the instantaneous peak current, their operating current, starting current, and current peak value are all different. Therefore, the rated value of the motor in the selection table can only represent guide data. The actual rated data and starting data of the motor are very important for selecting a suitable circuit breaker. This principle also applies to circuit breakers for transformer protection.

Application Categories

Motor protection
System protection
Starter combination short - circuit protection
Transformer protection
As main switches and emergency stop switches
DC circuits
