Siemens 3VU1640-1MK00 4-6A Motor Protection Circuit
Brand:
Series:
3VU (domestic)
Application:
Motor and line protection
Control Type:
Toggle control
Setting Current Range:
4-6A
Rated Power:
2.2KW
Auxiliary Contacts:
1NO+1NC
Wiring Method:
Screw terminals
Poles:
3P
Rated Voltage:
415VAC
Breaking Capacity:
100KA
Model:
3VU1640-1MK00 4-6A
Order Number:
3VU16401MK00
Description:
Siemens (domestic) 3VU1640-1MK00 4-6A, 2.2KW, breaking capacity 100KA, toggle control, motor and line protection, 415VAC, auxiliary contact 1NO+1NC,screw terminal, pole number 3P
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | 3VU (domestic) | |
| Application： | Motor and line protection | |
| Control Type： | Toggle control | |
| Setting Current Range： | 4-6A | |
| Rated Power： | 2.2KW | |
| Auxiliary Contacts： | 1NO+1NC | |
| Wiring Method： | Screw terminals | |
| Poles： | 3P | |
| Rated Voltage： | 415VAC | |
| Breaking Capacity： | 100KA |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Description
- 3VU13 and 3VU16 circuit breakers are compact - type circuit breakers with a maximum rated current of 63A.
- They work based on the current - limiting principle and can be used for starting motors or other loads, as well as for overload and short - circuit protection; 3VU13 and 3VU16 can also be used for motor phase - failure protection.
- When used for motor or equipment protection, the above - mentioned circuit breakers are equipped with an over - current instantaneous trip and a time - delayed overload trip. Since the starter combination device itself has overload protection, the 3VU16 used for starter combinations is only equipped with an over - current instantaneous trip. The circuit breaker and contactor can be combined to form a starter device without a fuse - type circuit breaker combination.
- 3VU13 and 3VU16 circuit breakers are suitable for any climate and are designed for good operating environments in enclosed rooms (such as dust - free, non - corrosive gas). Before being installed and used in dusty and humid rooms, they must be properly sealed and treated.
- Various working parameters of the circuit breaker: allowable ambient temperature, maximum breaking capacity, trip action current, and other restrictive operating parameters are given in the technical data and trip characteristics.
Circuit Breakers for Motor Protection
- 3VU13 0.1~25A
- 3VU16 1~52A
- The characteristic curves of these circuit breakers reflect the overload and short - circuit protection characteristics of the motor.
- The inverse - time overload trip can be set according to the rated current of the protected motor, and the instantaneous over - current trip device is preset at 12 times the rated current to ensure that it can pass the motor starting current.
Circuit Breakers for Transformer Protection
- 3VU13 40 - IT.00 0.1~20A
- These circuit breakers are used to protect the primary side of control transformers with high inrush currents.
- They are equipped with adjustable overload trip devices and preset instantaneous short - circuit current trip devices. The instantaneous trip action current is set at 19 times the operating current, which ensures that transformers with inrush current peaks reaching 30 times the rated current can work normally.
Circuit Breakers for Circuit Protection
- 3VU13 0.1~25A
- 3VU16 1~63A
- These circuit breakers are used for overload and short - circuit protection of cables, conductors, and electrical equipment.
- They have preset or adjustable overload and short - circuit trip devices to achieve the purpose of optimizing the adaptability of the distribution system.
Circuit Breakers for Starter Combination Devices
- 3VU16 1.6~52A
- In the starter combination device composed of contactors and thermal relays, these types of circuit breakers are used for short - circuit protection of such combination devices. They have preset short - circuit trip devices but no overload trip devices.
