TENGEN DZ108-20 20[14-20] Motor protection circuit

Name: TENGEN DZ108-20 20[14-20] Motor protection circuit
SKU: 01040010011

Brand:

TENGEN

Series:

DZ108

Application:

Overload and short circuit protection

Control Type:

Push-button control

Setting Current Range:

14-20A

Rated Power:

Auxiliary Contacts:

1NO+1NC

Wiring Method:

Front panel wiring

Poles:

Rated Voltage:

380VAC

Breaking Capacity:

1.5KA

Model:

DZ108-20 20[14-20]

Order Number:

01040010011

Description:

TENGEN DZ108-20 20[14-20], breaking capacity 1.5KA, push button control, overload and short circuit protection, 380VAC, auxiliary contact 1NO+1NC, front wiring, number of poles 3P

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	TENGEN
Series：	DZ108
Application：	Overload and short circuit protection
Control Type：	Push-button control
Setting Current Range：	14-20A
Rated Power：	-
Auxiliary Contacts：	1NO+1NC
Wiring Method：	Front panel wiring
Poles：	3P
Rated Voltage：	380VAC
Breaking Capacity：	1.5KA

Products with the same attribute : 0

Show details

Series Overview

Product Features

This series of plastic - cased circuit breakers is suitable for circuits with AC 50Hz, rated voltage up to 660V, and rated current from 0.16A to 63A. They are used for overload and short - circuit protection of motors and for infrequent starting of motors under normal conditions.
This product complies with GB14048.2 and GB14048.4 standards.
