Schneider LR9-F5567 Overload Relay

Name: Schneider LR9-F5567 Overload Relay
SKU: LR9F5567

Brand:

Schneider

Series:

LR9F

Setting Current Range:

60-100A

Applicable Contactor:

LC1-F115…F185

Product Type:

Electronic

Model:

LR9-F5567

Order Number:

LR9F5567

Description:

Schneider overload relay LR9-F5567, electronic, suitable for contactor LC1-F115...F185, setting current range 60-100A

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Schneider
Series：	LR9F
Setting Current Range：	60-100A
Applicable Contactor：	LC1-F115…F185
Product Type：	Electronic

Products with the same attribute : 0

Show details

Series Overview

The LR9F electronic protection relay is specifically suitable for motor operation scenarios.

It can provide the following protection functions:

Phase failure and phase imbalance;
Excessively long starting time;
Long - term rotor stalling.
The LR9F electronic protection relay is directly installed below the contactor of the LC1F type. Relays within the range from 30 to 630A have 8 rated values.
The setting dial can be locked through a transparent protective cover.
The reset button is installed on the front side of the relay.
