Schneider LRD10 Overload Relay

Name: Schneider LRD10 Overload Relay
SKU: LRD10

Brand:

Schneider

Series:

LRD

Setting Current Range:

4-6A

Applicable Contactor:

LC1D09-D38

Product Type:

Electric heating

Model:

LRD10

Order Number:

LRD10

Description:

Schneider overload relay LRD10, electric heating, suitable for contactor LC1D09-D38, setting current range 4-6A

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Schneider
Series：	LRD
Setting Current Range：	4-6A
Applicable Contactor：	LC1D09-D38
Product Type：	Electric heating

Products with the same attribute : 0

Show details

Series Overview

TeSys® thermal overload relays can provide the following protections for AC circuits and motors:

Overload
Phase failure
Excessive starting time
Excessive stalling time

Wiring Methods

LRD 01 to LRD 35

LRD 01 to 35 relays are connected via screw - clamped terminals.
Additionally, products connected using ring terminals can also be provided.

LRD 313 to LRD 365

LRD 313 to LRD 365 are connected via BTR spiral wiring devices (inner hexagon screws) (Schneider Electric patent).
These screws are tightened with a No. 4 insulated Allen wrench.
EverLink® terminals are used to compensate for the (1) effect of conductor creep, thus ensuring a lasting tightening effect.
These relays can also be connected via ring terminals.
This connection method meets the needs of some Asian markets and is suitable for occasions with strong vibrations, such as rail transit systems.

LRD 3361 to 4369, LRD 2

LRD 3361 to 4369 and LRD 2 relays are connected via screw - clamped terminals.
Additionally, products connected using ring terminals can also be provided.
