Delixi CJX112NM reversible contactor

Name: Delixi CJX112NM reversible contactor
SKU: CJX112NM

Brand:

Delixi

Series:

CJX1-N

Main Contacts:

3NO

Control Circuit:

AC 50Hz

Control Coil Voltage:

220VAC

Auxiliary Contacts:

2NO+2NC

Rated Current:

12A

Poles:

Rated Voltage:

380VAC

Model:

CJX1-12N 50HZ 220V

Order Number:

CJX112NM

Description:

380VAC, pole number 3P, control circuit AC 50Hz, control coil voltage 220VAC, main contact 3NO, auxiliary contact 2NO+2NC, 12A

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Delixi
Series：	CJX1-N
Main Contacts：	3NO
Control Circuit：	AC 50Hz
Control Coil Voltage：	220VAC
Auxiliary Contacts：	2NO+2NC
Rated Current：	12A
Poles：	3P
Rated Voltage：	380VAC

Products with the same attribute : 0

Show details

Series Overview

Product Description

Mainly used in power lines with AC 50Hz, a rated insulation voltage of up to 1000V, and a rated operating current of up to 300A to control the forward and reverse rotation of AC motors.

Product Features

A reversible contactor composed of 2 CJX1 contactors, interlocked by a mechanical interlocking mechanism to ensure that the two contactors cannot be closed simultaneously, effectively ensuring the normal forward and reverse rotation of the AC motor;
The JRS2 thermal overload relay can be directly plug - in installed on the mechanical interlocking contactor;
The mechanical interlocking mechanism has no impact on the action time of a single AC contactor.

Certificates

CCC, ROHS, CE certification certificates

Standards

IEC 60947 - 4 - 1/GB14048.4
