Huyu CJX2-4011N/220V reversible contactor
Brand:
Series:
CJX2-N
Main Contacts:
3NO
Control Circuit:
AC 50/60Hz
Control Coil Voltage:
220VAC
Auxiliary Contacts:
1NO+1NC
Rated Current:
40A
Poles:
3P
Rated Voltage:
380VAC
Model:
CJX2-4011N/220V
Order Number:
1010800368
Description:
380VAC, pole number 3P, control circuit AC 50/60Hz, control coil voltage 220VAC, main contact 3NO, auxiliary contact 1NO+1NC, 40A
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Huyu | |
| Series： | CJX2-N | |
| Main Contacts： | 3NO | |
| Control Circuit： | AC 50/60Hz | |
| Control Coil Voltage： | 220VAC | |
| Auxiliary Contacts： | 1NO+1NC | |
| Rated Current： | 40A | |
| Poles： | 3P | |
| Rated Voltage： | 380VAC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Product Information
- The CJX2 - N series mechanically interlocked contactors are suitable for circuits with AC 50Hz or 60Hz, a voltage of up to 660V, and a current of up to 95A. They are used for reversible control of motors and can form electromagnetic starters with appropriate thermal overload relays to protect circuits that may be overloaded.
- This product complies with GB14048.4 and IEC60947 - 4 - 1 standards.
Normal Operating Conditions
-
- Ambient air temperature: - 5°C ~ + 40°C, with the 24 - hour average value not exceeding + 35°C;
-
- Altitude: not exceeding 2000m;
-
- Atmospheric conditions: The relative humidity of the air at the installation site does not exceed 50% at + 40°C. Higher relative humidity is allowed at lower temperatures, for example, reaching 90% at 20°C. Special measures should be taken for condensation occasionally generated due to temperature changes;
-
- Pollution level: 3;
-
- Installation category: III;
-
- Enclosure protection level: IP20;
-
- Installation conditions: The inclination of the installation surface from the vertical plane is not more than ± 5°;
-
- Shock and vibration: Installed in a place without significant shaking, impact, and vibration.
-
- Transportation and storage: The contactor should not be subject to severe collisions and vibrations during transportation, and should not be exposed to rain and snow during transportation and storage. The contactor is suitable for transportation and storage at a temperature between - 25°C ~ + 55°C, and can be transported and stored at a temperature of up to + 70°C for a short time (within 24h).
