Siemens 3SB3000-4AD01 Selector switch accessories
Brand:
Series:
3SB3
Light Source:
-
Installation Diameter:
22mm
Number of Digits:
2
Handle Type:
-
Color:
-
Material:
plastic
Function:
Self-locking type
Product Type:
Key switch head
Model:
3SB3000-4AD01
Order Number:
3SB30004AD01
Description:
3SB3000-4AD01, Key Switch Head, Self-locking, Plastic, 2 Positions, Mounting Diameter 22mm
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | 3SB3 | |
| Light Source： | - | |
| Installation Diameter： | 22mm | |
| Number of Digits： | 2 | |
| Handle Type： | - | |
| Color： | - | |
| Material： | plastic | |
| Function： | Self-locking type | |
| Product Type： | Key switch head |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
- SIRIUS 3SB3 is a control device used for front - panel installation and rear - panel wiring, with two series: metal and plastic.
- The external design of SIRIUS is flat and has a streamlined shape, making the entire control panel very coordinated and beautiful. The slide - in installation structure is ingeniously designed, greatly improving the installation efficiency. In addition, the SIRIUS metal series has a very high protection level, reaching IP67 and NEMA4.
Standards
- IEC 60947, EN 60947 - 1 (DIN VDE 0660 Part 100), IEC 60947 - 5 - 1, EN 60947 - 5 - 1 (DIN VDE 0660 Part 200)
Design
- The plastic series has a flat shape, including circular and square. The metal series only has a circular shape.
- The flat shape makes the plastic series coordinate very well with the thin - faced panel and is easy to clean.
- The operating surface of the button and the illuminated button is concave. The lens of the indicator light is convex.
Inscriptions
- Inscriptions can be directly laser - engraved on the surface of the component, or engraved on the nameplate or backplane, and can also use a lettering system.
Structure
- A control device consists of three parts: the button head or light cover in front of the panel, the installation base behind the panel, and the contact block or lamp holder.
- The installation base of the circular series can be used on both sides. One side is suitable for panels with a thickness of 1 - 4mm, and the other side is suitable for panels with a thickness of 3 - 6mm.
- The installation base of the square series is only suitable for panels with a thickness of 1 - 4mm.
- The button with regular configuration can be installed with two contact blocks. When three contact blocks or one lamp holder + two contact blocks are needed, a 3 - position bracket (3SB3901 - 0AB) must be inserted at the rear of the button head. For knob switches, key switches, and double - button units, a 3 - position bracket (3SB3901 - 0AC) with a central contact actuator piece needs to be inserted.
- For the convenience of users in selecting models, we have set up order numbers for sets of devices for some commonly used models, which can meet the needs of most applications.
Base
- When delivered, the installation position of the base is suitable for panels with a thickness of 1 - 4mm, that is: the direction of the arrow for ▲1 - 4mm ▲ faces forward, and the tightening screw is at the lower right corner. When the panel thickness is 3 - 6mm, the base needs to be reversed, that is: the direction of the arrow for ▲3 - 6mm ▲ faces forward, and the tightening screw is at the upper right corner. In this case, the tightening screw must be turned counterclockwise to the end before installing the base.
Contact Blocks and Lamp Holders
- There is a slow - action contact with a double - break contact bridge structure (1NC or 1NO) inside the contact block. This structure ensures that the 3SB3 button switch still has high reliability even at low voltage and low current (such as 5V/1mA1). They are suitable for electronic systems and regular electrical control.
- The normally closed (NC) contact realizes the safety function through forced breaking.
- BA9s (screw connection) and Wx2×4.6d (solder connection) lamp holders can be used for illuminated buttons and signal lights.
- Both the contact block and the lamp holder have terminal markings that meet EN 50013.
Installation
- SIRIUS devices can be installed simply and quickly:
- Insert the button head or light head from the front of the control panel
- Install the base from the rear
- Tighten the screws on the base
- Snap the contact block or lamp holder directly onto the base
Wiring Methods
- Screw terminal blocks
- Cage - clamp terminal blocks
- Solder connection (0.8×0.8mm)
- The screw terminal block of 3SB3 has SUT (Screw Clamp Technology) wiring technology. The anti - loosening structure prevents the screw from detaching from the main body during transportation. When delivered, the screw is in a loose state. Open terminals, circular wiring holes, and push - in holes greatly improve installation efficiency. Electric screwdrivers can be used.
- Cage - clamp spring terminal blocks: fast installation and can be closely arranged.
Button Boxes
- For circular buttons, the plastic button box can be equipped with 1, 2, 3, 4, 6 control points. Control points more than 6 (circular or square buttons) can also be supplied as required.
Communicable SIRIUS 3SB3
- The 4I/4O AS - i user module with a chip can connect SIRIUS control components to the AS - i network system.
Connection Methods
- AS - i user module for circuit boards
- Single - piece connection method
- AS - i front panel module
- AS - i button box
- SIRIUS can also communicate with PROFIBUS - DP.
