TENGEN LAY7-11XD/31 Knob with light 220V red Selector switch

Name: TENGEN LAY7-11XD/31 Knob with light 220V red Selector switch
SKU: 08010140157

Brand:

TENGEN

Series:

LAY7

Base Material:

plastic

Light Source:

With light

Installation Diameter:

22.3mm

Number of Digits:

Handle Type:

Short handle

Color:

red

Function:

Self-locking type

Auxiliary Contacts:

1NO+1NC

Product Type:

Handle switch

Rated Voltage:

220VAC

Model:

LAY7-11XD/31 Knob with light 220V red

Order Number:

08010140157

Description:

Handle switch, short handle, auxiliary contact 1NO+1NC, 3 positions, base material plastic, red, self-locking

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	TENGEN
Series：	LAY7
Base Material：	plastic
Light Source：	With light
Installation Diameter：	22.3mm
Number of Digits：	3
Handle Type：	Short handle
Color：	red
Function：	Self-locking type
Auxiliary Contacts：	1NO+1NC
Product Type：	Handle switch
Rated Voltage：	220VAC

Products with the same attribute : 0

Show details

Series Overview

The LAY7 series button switches are suitable for industrial control circuits with an AC frequency of 50Hz, a rated working voltage of AC 380V and below or DC 220V and below. They are used for remote control in magnetic starters, contactors, relays and other electrical circuits. Button switches with indicator lights are also suitable for scenarios requiring optical signal indication.

Compliance Standards

GB14048.5

Ambient Temperature

Not lower than -5°C and not higher than +40°C, with a 24h average value not exceeding +35°C.

Altitude

Not exceeding 2000m.

Atmospheric Conditions

The relative humidity of the surrounding air is 45% - 85% (no condensation).
No significant shaking and impact vibration.
In a medium without explosion danger, and there is no gas and dust in the medium that can corrode metals and damage insulation. In a place not invaded by rain and snow.

Pollution Degree

Level 3.

Installation Category

Category II.

Structural Features

The contact element has a double - break point type with two wiring terminals.
The normally open and normally closed contacts are separated in structure and insulated in electricity, and can work with different polarities.
Contact groups can be combined arbitrarily, convenient for replacement.
Equipped with an anti - rotation positioning ring, with accurate and reliable positioning.
The wiring terminals uniformly use M3.5 combination screws.
