TENGEN TGLA39-11CX red Selector switch
Brand:
Series:
TGLA39
Base Material:
plastic
Light Source:
-
Installation Diameter:
22.3mm
Number of Digits:
2
Handle Type:
Long handle
Color:
red
Function:
Self-locking type
Auxiliary Contacts:
1NO+1NC
Product Type:
Handle switch
Rated Voltage:
-
Model:
TGLA39-11CX Red
Order Number:
08010170035
Description:
Handle switch, long handle, auxiliary contact 1NO+1NC, 2 positions, base material plastic, red, self-locking
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | TENGEN | |
| Series： | TGLA39 | |
| Base Material： | plastic | |
| Light Source： | - | |
| Installation Diameter： | 22.3mm | |
| Number of Digits： | 2 | |
| Handle Type： | Long handle | |
| Color： | red | |
| Function： | Self-locking type | |
| Auxiliary Contacts： | 1NO+1NC | |
| Product Type： | Handle switch | |
| Rated Voltage： | - |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
- This series of products is suitable for use in electromagnetic starters, contactors, relays, and other electrical circuits with an AC frequency of 50HZ (or 60Hz), a voltage below 660V, and a DC voltage of 440V and below for remote control purposes. Button switches with indicator lights are also suitable for scenarios that require optical signal indication.
Compliance Standards
- GB14048.5
Ambient Temperature
- Not exceeding +40°C, and the average temperature within 24 hours does not exceed +35°C. The lower limit of the ambient air temperature is -5°C.
Altitude
- Not exceeding 2000m.
Atmospheric Conditions
- When the maximum temperature is +40°C, the relative humidity of the air does not exceed 50%; higher relative humidity is allowed at lower temperatures. For example: reaching 90% at +20°C; special measures shall be taken for condensation occasionally generated due to temperature changes.
Pollution Degree
- Level 3.
Installation Category
- Category II.
Structural Features
- The contact system of this series of button switches adopts a lever - type over - center toggle mechanism. During operation, even if the pressing stroke is insufficient, as long as it exceeds the critical flip position, it can act quickly, and can reliably contact or disconnect. Through the action of the tension spring, the necessary contact pressure is ensured, and it has a self - cleaning function, making the contact reliable and the arc - extinguishing performance good. When switching on and off, due to the jumping of the metal sheet, a clear sound is emitted, giving the user a signal to let them know whether the command is executed.
- Combined clamping method: Assembly and disassembly are flexible, convenient, and reliable; it can be equipped with two - section switch elements, with 1 - 4 pairs of contacts, and can form 1 - 14 specifications.
- Normally open and normally closed are electrically insulated and can work with different polarities.
- There is an anti - partition at the wiring place, and the combination screw is used for crimping. Its tile - shaped washer rises or falls as the screw is screwed out or in, making wiring convenient.
- The installation method adopts an oblique screw for fixing, which is not only convenient but also safe and reliable.
