6SL3162-0AD00-0AA1 Siemens

Name: 6SL3162-0AD00-0AA1 Siemens
SKU: 6SL3162-0AD00-0AA1

Brand:

Siemens

Country of Origin:

Germany

Delivery Time:

Estimated delivery time is 3 to 15 days (for reference only, please contact customer service for detailed information).

Degree of Protection:

IP20

Model:

6SL3162-0AD00-0AA1

Order Number:

6SL3162-0AD00-0AA1

Description:

SINAMICS S120 shield plate used for mounting and grounding cable shields, ensuring EMC compliance and reducing electromagnetic interference in drive systems

WhatsApp Inquire Now

Product parameters
Product Overview
File
frequently asked questions

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Siemens
Country of Origin：	Germany
Certificate of suitability：	CE, RoHS
Max. operation：	60°C
Transport：	Industrial-grade packaging (anti-static, shockproof.)
Storage：	-25°C to 70°C
Operation：	0°C to 60°C
Display design：	No display
Net weight：	0.6 kg
Packaging dimensions(LxWxH)：	220 × 150 × 50 mm
Delivery Time：	Estimated delivery time is 3 to 15 days (for reference only, please contact customer service for detailed information).
Life Cycle：	/
ECCN：	N
AL：	N
Product Overview：	SINAMICS S120 shield plate used for mounting and grounding cable shields, ensuring EMC compliance and reducing electromagnetic interference in drive systems
Degree of Protection：	IP20

Products with the same attribute : 0

Show details

Product Overview

File

6SL3162-0AD00-0AA1.pdf

Frequently asked questions

Is it suitable for heavy-duty industrial applications?

Yes. Its robust design ensures stable performance under high-load and continuous operation conditions.
How does it affect EMC?

It improves electromagnetic compatibility by reducing high-frequency disturbances and conducted emissions.
Does it require active cooling?

No, the reactor operates reliably without additional cooling mechanisms.
Can it be installed in retrofitted systems?

Yes. Its compact and passive design allows easy integration into existing drive installations.
Is it effective for long cable runs?

Yes. It mitigates reflected wave issues, which are common when motors are located far from drives.
How does this reactor protect the motor?

It reduces voltage spikes and dv/dt stress, safeguarding motor insulation and extending operational lifespan.
