6SL3162-0AN00-0AA0 Siemens
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Country of Origin： | Germany | |
| Certificate of suitability： | CE, RoHS | |
| Max. operation： | 60°C | |
| Transport： | Industrial-grade packaging (anti-static, shockproof.) | |
| Storage： | -25°C to 70°C | |
| Operation： | 0°C to 60°C | |
| Display design： | No display | |
| Net weight： | 0.15 kg | |
| Packaging dimensions(LxWxH)： | 80 × 50 × 25 mm | |
| Delivery Time： | Estimated delivery time is 3 to 15 days (for reference only, please contact customer service for detailed information). | |
| Life Cycle： | / | |
| ECCN： | EAR99H | |
| AL： | N | |
| Product Overview： | SINAMICS S120 connection accessory (terminal/connection component), used for electrical connection and installation support in S120 drive systems | |
| Degree of Protection： | IP20 |
Product Overview
Frequently asked questions
-
Does it also protect the inverter?
Yes. By smoothing current flow and reducing back-reflected energy from long cables, it helps minimize drive component heating and prevents nuisance tripping during demanding load cycles.
-
Can it extend the life of older motors?
Absolutely. Many legacy motors were not built with insulation capable of handling high PWM stress. A reactor reduces these stressors and helps prevent premature motor failure.
-
Is installation complicated?
Installation is straightforward and typically involves wiring the reactor between the inverter and the motor. Mechanical mounting requires standard cabinet space, and no special cooling units are needed for normal operation.
-
Does it affect motor performance?
It slightly reduces voltage at the motor terminals, but the benefit of reduced insulation stress and smoother current far outweighs the minor voltage drop. Performance remains stable and often improves in long-cable applications.
-
Can it help reduce electromagnetic noise?
Yes. By attenuating high-frequency switching components, it significantly reduces radiated and conducted EMI. This helps maintain stable performance in facilities with sensitive electronics or dense automation wiring.
-
Why would I need a motor reactor with a SINAMICS drive?
A motor reactor protects both the drive and the motor by smoothing the steep voltage pulses generated by PWM switching. This is crucial when cable lengths exceed recommended levels or when motors have older insulation not designed for modern fast-switching drives.
