Delixi CDG2-DA 120A Solid State Relay

Name: Delixi CDG2-DA 120A Solid State Relay
SKU: CDG2DA120A

Brand:

Delixi

Series:

CDG2

Operating Voltage:

24-480VAC

Control Voltage:

3-32VDC

LED Indicator:

have

Rated Current:

120A

Installation:

Base plate installation

Model:

CDG2-DA 120A

Order Number:

CDG2DA120A

Description:

Delixi solid state relay CDG2 CDG2-DA 120A, control voltage 3-32VDC, 120A, baseboard installation, working voltage 24-480VAC, LED indicator

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Delixi
Series：	CDG2
Operating Voltage：	24-480VAC
Control Voltage：	3-32VDC
LED Indicator：	have
Rated Current：	120A
Installation：	Base plate installation

Products with the same attribute : 0

Show details

Series Overview

Scope of Application

This product is a new type of contactless electronic switch. It not only replaces electromechanical relays but is also widely used in digital program - controlled devices, motor control devices, temperature adjustment devices, data processing systems, and computer terminal interface circuits. It is especially suitable for special occasions with frequent actions, explosion - proof, moisture - proof, and corrosion - resistant requirements.

Advantages

Small volume, capable of directly driving large - current loads with tiny control signals.
Adopts high - quality chips and high - grade chip support plates, with special welding processes, no gaps in the welding layer, and more reliable use.
Uses high - grade thermally conductive and insulating materials, with good thermal conductivity. The thermal conductive bottom plate is non - live, ensuring safe use.
Uses LED indicators and high - strength epoxy resin sealing, with better explosion - proof and anti - corrosion performance, and an attractive appearance.

Product Features

This solid - state relay is composed of a shell, an electronic circuit board, a flame - retardant engineering plastic shell, a metal heat - dissipation bottom plate, and a thyristor. It uses a dedicated photoelectric coupler for isolation and has the advantages of stable and reliable operation, fast switching speed, high operating frequency, long service life, low noise, low power consumption, an attractive appearance, and convenient installation and use.

Working Conditions

Ambient temperature: - 30°C - 70°C
Load voltage: 24 - 480VAC
Altitude: ≤2000 meters
Installation category: Ⅱ
Pollution level: Level 3

Installation Conditions

When the load current is higher than 10A, a heat sink must be used, and thermal conductive silicone must be applied between the heat - dissipation bottom plate of the solid - state relay and the installation surface of the heat sink. For currents above 60A, an additional fan for forced cooling is required.
