Phoenix VS-SI-EB-EMV-1 Terminal Accessory
Brand:
Series:
Bracket
Color:
-
Material:
-
Product Type:
Mounting bracket
Model:
VS-SI-EB-EMV-1
Order Number:
1656482
Description:
Phoenix terminal accessory bracket VS-SI-EB-EMV-1, Mounting Bracket
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Phoenix | |
| Series： | Bracket | |
| Color： | - | |
| Material： | - | |
| Product Type： | Mounting bracket |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Neutral Busbar Brackets
Three types of brackets can be selected to support neutral busbars:
- The AB/SS series is installed on the same - specification guide rail
- AB 2/SS is used for the staggered arrangement of neutral wires and PE grounding wires
- Lower layer ABN 2/SS
Brackets for Direct Installation
The following types of brackets can be selected:
- AB/SS for insulated installation on the mounting panel
- AB/SS-M for non-insulated installation on the mounting panel
- For installing shielded connection terminals SK and SKS
Multi-layer Brackets for Direct Installation
- Double and triple-layer brackets for different busbars
- This type maintains a very compact design while handling a large number of wires, for example, for multi-layer front connection terminals
- Insulated brackets
- Direct installation
Installation Accessories
- Bracket equipment can be used to support fully insulated DIN guide rails
- Terminal blocks NS 35/... CAP can be connected to the ends of NS 35/7.5 and NS 35/15 DIN guide rails
Brackets for Shielding on One Side
AB-SK TOP
- Facilitates shielded connections, especially suitable for single-layer and multi-layer terminals and equipment with the wire inlet at the front
- 3 x 10 mm guide rails can be installed vertically, horizontally, and at a 45-degree angle within the bracket to optimize wire routing
- Thickness is only 5.2 mm
- Can be marked with plug-in type labels and KLM... terminal strip labels
- For inserting bridging components FBS
- Terminal bracket function
- For installing shielded connection terminals SK and SKS
AB-SK
- Single-side shielding bracket AB-SK is especially suitable for terminals and equipment with the wire inlet on the side, saving space
- Two lengths can be selected
- For installing shielded connection terminals SK
AB-SKS
- Facilitates shielded connections for single-layer and multi-layer terminals and equipment with front wiring
- Insulated from DIN guide rails
- Terminal bracket function
- For installing shielded connection terminals SK and SKS
AB-SK 65-D
- Double shielding bracket is especially suitable for terminal box equipment with the wire inlet on the side, saving space
- Two lengths can be selected
- For installing shielded connection terminals SK
Brackets for Direct Installation of Enclosed DIN Guide Rails
- T-shaped brackets for space-saving direct installation and installation at any position on the mounting panel
- Suitable for shielded connection terminals SK 5 to SK 14, SKS 8 and SKS 14
- Model for NS 35 DIN guide rail installation
Flat Brackets for Fixing DIN Guide Rails
- BG/5 brackets can fix DIN guide rails at short intervals on the mounting surface
Covers
- Protective covers can prevent unauthorized use of terminal strips
- Large-area identification can be achieved with AP-ES plug-in type labels
Identification Brackets
- Self-adhesive identification brackets are supplied as received or can be shortened as required
- Have strong adhesion and clamping force on the surface of standard equipment
- P-SS-ZB100 is specially designed for installing S-ZB, UC-EM (20X9), UCT-EM (20X9)
- P-ZB METER can accommodate identification materials on the vertical and horizontal identification slots of Phoenix Contact electrical combined terminals
