Schneider RE17RLMU Time Relay
Brand:
Series:
RE17
Time Range:
1s-100h
Output Type:
Relay output
Supply Voltage:
24VDC, 24-240VAC
Contact Type:
1C/O
Rated Current:
8A
Product Type:
DIN Rail Mount Relays
Model:
RE17RLMU
Order Number:
RE17RLMU
Description:
Schneider time relay RE17RLMU, rail mounted relay, power supply voltage 24VDC, 24-240VAC, contact type 1C/O, relay output, time range 1s-100h,8A
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Schneider | |
| Series： | RE17 | |
| Function： | L, Li | |
| Time Range： | 1s-100h | |
| Output Type： | Relay output | |
| Supply Voltage： | 24VDC, 24-240VAC | |
| Contact Type： | 1C/O | |
| Rated Current： | 8A | |
| Product Type： | DIN Rail Mount Relays |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
- A time relay is a component in industrial automation systems for time management that can close or open contacts before, during, or after a set timing cycle.
Time relays mainly have 2 installation types:
- DIN rail - mounted time relays (RE7, RE9, RE17, RE22...): Can be directly installed on a DIN rail through the slot at the back of the relay housing.
- Base - mounted time relays (REX1): Installed with a plug - in base.
- Panel - mounted time relays (RE48): Designed to be installed on the front of the panel for user convenience in setting.
These relays have 1, 2, or 4 outputs. The 2nd output can be a delayed output or an instantaneous output.
If the power supply is cut off during the timing period, the relay will return to the initial position.
Application Examples
- Automatic door opening
- Alarms
- Toilet lighting
- Parking lot barriers
The following definitions help you understand the working principles of these relays:
- Relay output: This is the most common output type. When the relay is powered on, the armature is attracted by the coil to trigger the contacts, thereby changing the contact state. When the relay loses power, the armature and contacts return to their original positions.
- Solid - state output: These outputs are fully electronic and have no mechanical moving parts; thus, they can have a longer service life.
- Breaking capacity: The current value that the contacts can break under specified conditions.
- Mechanical life: The number of mechanical operation cycles of the contacts.
- Minimum switching capacity (or minimum electrical capacity): The minimum current required to allow the relay contacts to switch.
- GI (Gate) output: The gate output allows interrupting the ongoing timing without the need for resetting.
