Phoenix ST 2,5-DIO/LR (3036262) Universal combination terminal ST
Brand:
Series:
ST
Terminal Type:
Functional
Color:
grey
Material:
PA
Conductor Cross-Sectional Area:
2.5mm²
Flame Retardant Grade:
V0
Connection:
Spring-cage connection
Terminal Thickness:
5.2mm
Function:
Component terminals
Rated Current:
0.5A
Rated Voltage:
800V
Model:
ST 2,5-DIO/LR(3036262)
Order Number:
3036262
Description:
Phoenix 2,5-DIO/LR (3036262), material PA, 800V, V0, al component terminal, color gray, wire cross-sectional area 2.5mm², terminal thickness 5.2mm, pull-back spring connection
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Phoenix | |
| Series： | ST | |
| Terminal Type： | Functional | |
| Color： | grey | |
| Material： | PA | |
| Conductor Cross-Sectional Area： | 2.5mm² | |
| Flame Retardant Grade： | V0 | |
| Connection： | Spring-cage connection | |
| Terminal Thickness： | 5.2mm | |
| Function： | Component terminals | |
| Rated Current： | 0.5A | |
| Rated Voltage： | 800V |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Three-wire Starter/Actuator Terminal STIO 2,5/3
- Used to connect three-wire starters and actuators, saving time and space.
- The upper layer is used for the wiring of the main circuit, and the two lower layers are used to distribute the positive and negative poles.
- Power can be supplied via lateral electrical connections STIO-IN.
- Through modular electronics, it can be installed at any position of the busbar for power supply expansion.
- Using the plug-in bridge connectors of the CLIPLINE complete series, bridging and equipotential distribution can be conveniently realized.
- The three-wire output (same as PE connection) is on the lower layer, used to connect the actuator.
- With an indicator light to display the on-off status.
Four-wire Starter/Actuator Terminal STIO 2,5/4...
- Used to connect four-wire starters and actuators, saving time and space.
- The upper layer is used for signal wiring.
- The lower layer (electrical connection) has an external ground conductor connection.
- Directly connected to the DIN rail, and the marking of the PE connection point is clear.
- Through lateral electrical connections STIO-IN, the positive pole, negative pole, and PE can be connected.
- Additional connections can be made in the CLIPLINE complete system through flat jumper electrical connectors.
- In the CLIPLINE complete system, through plug-in bridge connectors B... for lateral equipotential distribution, individual connection points can be connected through 松开 plug-in pins.
- With an indicator light to display the on-off status.
Potential Distribution Terminal ZPV 1,5/2,5 (8/1)
- Actuators and distributed starters can be supplied with electrical working voltage simply and clearly.
- The working voltage is provided through a 2.5 mm² return spring connection and distributed through eight 1.5 mm² connections.
- Mainly used in small control cabinets of compact control systems.
Cantilever Fuse and Disconnect Terminal ST...-HESI/-HEDI
Features of cantilever fuse terminal blocks:
- Ultra-compact design.
- The through-channel bridge connection means that all potential distribution work can be completed quickly. For example, conversion bridge connectors can be used to wire two separate potentials in parallel.
- There are test holes on both sides of the fuse.
- With an indicator light to indicate the blown status of the fuse.
Fuse Terminal for Automatic Flat Fuses ST 4-FSJC...
- Fuse terminals ST 4 and FSJC can install flat fuses or TCP../DC32V thermal fuses (complying with ISO/DIS 8820/DIN 72581-3 standards).
- Terminals with indicator lights can indicate the blown status of the fuse.
Knife Disconnect Terminal ST...-DMT
- Compact knife disconnect terminal with a current-carrying capacity of 20 A.
- Plug-in bridge connections can be used for power supply and potential distribution, saving time.
- Test connections can be made on both sides, with a test interface of 2.3 mm.
- Three-wire and four-wire terminals can be used for multi-wire connections.
- Upper-layer connection is very convenient.
Double-layer Knife Disconnect Terminal
Provide double-layer knife disconnect terminals of different models that save space.
- There are disconnect knives on the upper layer.
- There are disconnect knives on both layers, and the high misalignment indicates that the disconnect knives are distributed to different layers.
- There are test connections on both sides of the isolation layer for a 2.3 mm test interface.
- The bridge connection provides the range of potential distribution.
ZDMITK 2,5-TWIN
- If a higher input signal needs to be divided into two disconnect points, ZDMTK 2,5-TWIN is required.
ST 2,5...-DIO... Diode Terminal
- Diode terminals can perform a large number of switching tasks.
- The width of the diode terminal is 5.2 mm or 6.2 mm.
- Terminals with diodes have a conduction direction from left to right or right to left.
- Three-wire and four-wire terminals can be used for multi-wire connections.
- ST 4-QUATTRODIO provides a large continuous current of up to 1.5 A through an N 5408 diode.
Double-layer Terminal for Diodes and Optoelectronic Diodes STTB 2,5...
- Double-layer diodes and indicator lights can perform a large number of different switching tasks.
Three-layer Building Terminal STI...
- Ultra-compact design for easy operation.
- Quick connection of the load circuit, with an interval of only 5.2 mm.
- Each connection point can be clearly marked.
