Phoenix HV M5/1(3049107) Universal combination terminal RT

Name: Phoenix HV M5/1(3049107) Universal combination terminal RT
SKU: 3049107

Brand:

Phoenix

Series:

Terminal Type:

Functional

Color:

grey

Material:

Conductor Cross-Sectional Area:

16mm²

Flame Retardant Grade:

Connection:

Bolted connections

Terminal Thickness:

13mm

Function:

High current terminals

Rated Current:

76A

Rated Voltage:

1000V

Model:

HV M5/1(3049107)

Order Number:

3049107

Description:

Phoenix RT HV M5/1 (3049107), material PA, 1000V, V0, high current terminal, color gray, wire cross-sectional area 16mm², terminal thickness 13mm, bolt connection

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Phoenix
Series：	RT
Terminal Type：	Functional
Color：	grey
Material：	PA
Conductor Cross-Sectional Area：	16mm²
Flame Retardant Grade：	V0
Connection：	Bolted connections
Terminal Thickness：	13mm
Function：	High current terminals
Rated Current：	76A
Rated Voltage：	1000V

Products with the same attribute : 0

Show details

Series Overview

RT terminal blocks adopt a reinforced design and are easy to route with the help of annular cable ends. The feature of this series of terminal blocks is that their outer shell covers can be opened upwards and contain wiring nuts. This ensures quick and convenient connection of annular cable ends.
The built-in screw self-locking system, shaped like a spring sheet, ensures the safe application of the system in environments with strong vibration and impact.
This series of terminal blocks can connect all annular cold-pressed terminals that meet the following standards (DIN 46234, DIN 46235 and DIN 46237).
A prominent feature of bolt connection is multi-conductor connection. That is, if needed, one bolt can connect up to four cable ends at most.
Therefore, the bolt terminal block series can ensure the safe and reliable connection of all types of wires with a rated cross-section of 240 mm², and has long-term stability.
