Phoenix PT 2,5-QUATTRO/2P(3209662) Universal combination terminal COMBI

Name: Phoenix PT 2,5-QUATTRO/2P(3209662) Universal combination terminal COMBI
SKU: 3209662

Brand:

Phoenix

Series:

COMBI

Terminal Type:

Straight type

Color:

grey

Material:

Conductor Cross-Sectional Area:

2.5mm²

Flame Retardant Grade:

Connection:

Plug-in/plug-in connection

Terminal Thickness:

5.2mm

Function:

Rated Current:

24A

Rated Voltage:

500V

Model:

PT 2,5-QUATTRO/2P(3209662)

Order Number:

3209662

Description:

Phoenix COMBI 2,5-QUATTRO/2P (3209662), material PA, 500V, V0, color gray, wire cross-sectional area 2.5mm², terminal thickness 5.2mm, plug-in/plug-in connection

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Phoenix
Series：	COMBI
Terminal Type：	Straight type
Color：	grey
Material：	PA
Conductor Cross-Sectional Area：	2.5mm²
Flame Retardant Grade：	V0
Connection：	Plug-in/plug-in connection
Terminal Thickness：	5.2mm
Function：	-
Rated Current：	24A
Rated Voltage：	500V

Products with the same attribute : 0

Show details

Series Overview

The CLIPLINE complete universal modular terminal blocks provide a unified accessory system for various connection technologies. The marking and testing accessories all have unified standard specifications, which can help users improve assembly efficiency. In addition, all modular terminal block systems adopt dual-channel bridging technology to achieve arbitrary bridging. The plug-in terminal block COMBI series products, through standardized plug-in areas, allow the bases and plugs of various connection technologies to be combined arbitrarily.

Material Properties

All metal parts of the COMBI connector are made of corrosion-resistant materials. The distinction between electrical and mechanical functions is very convenient. The conductive metal is a high-grade copper alloy material. The surface is coated with lead-free, zinc-nickel or tin. The built-in cover spring is made of high-strength nickel-chromium spring steel sheets, and the contacts have a large current-carrying capacity.
The insulating shell of the COMBI connector is made of recyclable PA6.6. This elastoplastic material has high strength, contains no halogens, and is UV-resistant. In addition, it has good resistance to tropical climates and termite infestation, high resistance to chemical corrosion, and perfect anti-aging properties. The working temperature of PA6.6 can reach 130°C, and the flame retardant rating meets UL 94 V0.

Connection Principle

The COMBI pluggable connection is safe and reliable, and can meet customer needs to the greatest extent.
The COMBI series pluggable terminal blocks have a unified plug-in function area, so the plugs and base terminal blocks of the four connection methods can be freely combined.
Due to the adoption of a modular structure, users can assemble plugs and adapters by themselves. Various copper wires can be connected without pre-treatment. It can also prevent wire branching through cold pressing. The COMBI connector with various connection methods has a large wiring capacity. For example, rated cross-section wires with insulated sleeves and cold-pressed terminals can also be inserted.
