Phoenix PTTB 2,5-PE (3210596) Universal combination terminal PT
Brand:
Series:
PT
Terminal Type:
Grounding Type
Color:
Yellow and green
Material:
PA
Conductor Cross-Sectional Area:
2.5mm²
Flame Retardant Grade:
V0
Connection:
Push-in connection
Terminal Thickness:
5.2mm
Function:
Ground terminal
Rated Current:
-
Rated Voltage:
-
Model:
PTTB 2,5-PE(3210596)
Order Number:
3210596
Description:
Phoenix PTTB 2,5-PE (3210596), material PA, V0, al grounding terminal, color yellow and green, wire cross-sectional area 2.5mm², terminal thickness 5.2mm, direct plug-in connection
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Phoenix | |
| Series： | PT | |
| Terminal Type： | Grounding Type | |
| Color： | Yellow and green | |
| Material： | PA | |
| Conductor Cross-Sectional Area： | 2.5mm² | |
| Flame Retardant Grade： | V0 | |
| Connection： | Push-in connection | |
| Terminal Thickness： | 5.2mm | |
| Function： | Ground terminal | |
| Rated Current： | - | |
| Rated Voltage： | - |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
PT... Direct Plug-in Terminal Blocks
Direct plug-in terminal blocks not only have the characteristics of the CLIPLINE complete system but also have the following features:
- Can directly connect conductors with sheaths or rigid conductors without tools.
- Can use PT 2.5 (starting from 0.34 mm²) or PT 4 (starting from 0.5 mm²) to directly connect flexible conductors with crimped ends.
- The integrated operating button allows you to release the conductor with any tool before the connection, and live parts can be operated in a small space.
- Compact design and front-side non-contact potential distribution save time.
- When the test hole is in the through-channel bridge, all terminals provide an additional test connection for the terminal strip.
- We produce pre-assembled terminal strips that can be directly installed in control cabinets or switching systems. This simplifies installation, saves time, and reduces costs.
PT... Direct Plug-in Terminal Blocks
Double bridges can not only realize continuous modular bridging but also realize the conversion bridging from large cross-section terminal blocks to small cross-section ones.
PT...-TWIN One-in Two-out Direct Plug-in Terminal Blocks
Insertable multi-conductor modular terminal blocks, single-side connection:
- Multi-conductor connection can be realized without additional bridges, saving space.
- Easily realize potential distribution.
- Continuous dual-function transmission bridges can save potential distribution time as much as possible.
Supplementary Filler Plates
If two-wire terminals are arranged next to three-wire and four-wire terminals, the supplementary filler plates can cover the protruding parts.
- Prevent finger contact.
PT...-TWIN One-in Two-out Direct Plug-in Terminal Blocks
Double bridges can not only realize continuous modular bridging but also realize the conversion bridging from large cross-section terminal blocks to small cross-section ones.
- One-in two-out and two-in two-out terminal block product structures are compact, very suitable for power distribution loops or 1000 V solar power generation equipment.
- Large wiring capacity, can connect solar energy equipment with a conductor outer diameter of up to 7.5 mm.
- CLIP PROJECT Planning can help users quickly, conveniently, and correctly plan and combine terminal blocks.
PT...-QUATTRO Two-in Two-out Direct Plug-in Terminal Blocks
This series of terminal blocks can be used as compact power distribution terminals.
- Through multiple plug-in bridge connectors FBS..., can be cross-connected to any number of terminals.
