Schneider ATV-310HU22N4A Universal Inverter ATV310A
Brand:
Series:
ATV310A
Protection Level:
IP20
Control Panel:
Standard
Communication Protocol:
Modbus
Voltage Level:
Three-phase 380-460VAC
Rated Power:
2.2KW
Rated Current:
5.5A
Model:
ATV-310HU22N4A
Order Number:
ATV310HU22N4A
Description:
Schneider general purpose inverter ATV310A ATV-310HU22N4A, remote display terminal optional, 2.2KW, communication protocol Modbus, IP20, 5.5A, three-phase 380-460VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Schneider | |
| Series： | ATV310A | |
| Remote Display Terminal： | Alternative | |
| Protection Level： | IP20 | |
| Control Panel： | Standard | |
| Communication Protocol： | Modbus | |
| Voltage Level： | Three-phase 380-460VAC | |
| Rated Power： | 2.2KW | |
| Applications： | Various simple mechanical operations | |
| Rated Current： | 5.5A |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Product Introduction
The ATV 310A frequency inverter is designed for asynchronous motors with a three - phase voltage of 380V(-15%)... 460V(+10%), and the power range is 0.37kW to 11kW.
The design of the ATV 310A frequency inverter considers the following aspects to achieve plug - and - play:
- Compact size
- Integrated functions
- Optimized motor control
- Macro configuration function
The ATV 310A is particularly suitable for general industrial machinery and equipment
During the product design stage, relevant needs during installation and use are fully considered:
- The digital operation menu is more in line with the operating habits of Chinese users
- Operating at 55 degrees without reducing the rated working current
- IP41, top protection
- All circuit boards are treated with enhanced coating
The ATV 310A is a cost - effective frequency inverter worthy of trust for OEM customers.
Application Machinery
The multiple functions integrated in the ATV 310A frequency inverter fully meet the applications in the following industries:
- Textile machinery
- Ceramic machinery
- Woodworking machinery
- Machine tools
- Packaging and printing machinery
- Material handling equipment and other general machinery
Integrated Functions
- The ATV 310A integrates powerful functions in various aspects
Easier Integration
- The ATV 310A frequency inverter has a built - in Modbus communication protocol
- Logic input can be configured as source type, sink type, and floating type through software, compatible with all PLC systems
Easier Installation
The ATV 310A frequency inverter is easier to wire:
- The power terminals have clear labels to avoid wiring errors.
- For the control terminals, the labels are directly attached to the terminals for easy identification.
- The wiring guides inside the cabinet ensure correct installation
The ATV 310A frequency inverter supports side - by - side and compact installation, saving space inside the cabinet
Easier Commissioning with Integrated Panel
- The 4 - digit digital display can be used to display status and faults, and the navigation buttons can be used to modify parameters and access parameters. Remove the protective cover from the door cover to operate the run and stop buttons. These two buttons need to be set to be effective.
Remote Display Terminal
- The ATV 310 frequency inverter can be connected to a remote display terminal (provided as an accessory). This terminal can be installed on the cabinet door, reaching the protection level of IP54 or IP65. The maximum working temperature is 50°C. The functions accessible by this terminal are the same as those of the frequency inverter operation panel.
