Schneider INS800 3P load disconnect switch
Brand:
Series:
INS
On/Off Load Type:
Mixed Load
Handle Type:
Operating handle inside the cabinet
How It Works:
Frontal Operation
Rated Current:
800A
Poles:
3P
Rated Voltage:
690VAC
Installation:
Base plate/DIN rail installation
Model:
INS800 3P
Order Number:
31330
Description:
Schneider INS800 3P, front operation, in-cabinet operating handle, mixed load, 3P, base plate/DIN rail installation, 690VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Schneider | |
| Series： | INS | |
| On/Off Load Type： | Mixed Load | |
| Handle Type： | Operating handle inside the cabinet | |
| How It Works： | Frontal Operation | |
| Rated Current： | 800A | |
| Poles： | 3P | |
| Rated Voltage： | 690VAC | |
| Installation： | Base plate/DIN rail installation |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Advantages
- High reliability: Can be operated with load, no need for regular maintenance.
- Multiple choices: Front/side rotary handle, INV has visible break points.
- High safety: Cabinet - external operating handle with locking function, can be equipped with up to 3 padlocks at most; The whole series of products include emergency disconnect products with yellow panels and red handles.
Applications
- Schneider Electric ComPacT INS/INV series isolating switches, with nearly 50 years of electrical experience focusing on customer needs, focusing on delicate and sophisticated quality, simple and ingenious design appearance, and safe and reliable product performance, are widely used in power distribution protection in fields such as residences, public buildings, civil buildings, and small - to - medium - sized industries.
Reverse Power Supply
- ComPacT INSm isolating switches can be powered (incoming line) via top or bottom terminals without derating for use.
Neutral Pole Position
- In Schneider Electric isolating switches, the neutral pole is usually placed on the left - hand side. In the INSm series, the 3 electrodes are the same, so only an appropriate label needs to be added to make the neutral pole located on the right - hand position.
Conductor Materials and Electric Force
- ComPacT isolating switches can be connected using bare tinned copper conductors, tinned copper conductors (soft or hard busbars, cables).
- In case of short - circuit, heat and electric force are exerted on the conductors. Therefore, the conductors must have sufficient dimensions and proper support.
- Note that the terminals of electrical equipment (isolating switches, contactors, current circuit breakers, etc.) should not be used to support the conductors.
