Tube Fans-The power of flexibility
Brand:
Max Air Output:
The maximum air volume at 0 Pa ranges from 2,300 to 17,300 m³/h for single-phase models, and from 2,350 to 21,400 m³/h for three-phase models.
Applications:
Primarily used in Agricultural environments (such as pig, poultry, and dairy facilities), Horticulture (greenhouses), and Industrial buildings. They support both horizontal and vertical mounting orientations.
Product Category:
Tube Fans
Impeller Diameter:
Standard nominal sizes span from 30 cm to 92 cm. Customized fan diameters can be fabricated between 300 mm and 963 mm to fit specific customer requirements.
Model:
Tube Fans-The power of flexibility
Order Number:
Tube Fans-The power of flexibility
Description:
Tube Fans-The power of flexibility
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Multifan | |
| Motor Warranty： | Offers a standard 3-year warranty on the motor and fan components. | |
| Motor Protection Rating： | Features a water and dust resistant fan motor rated at IP55. | |
| Energy Efficiency / SFP： | Specific Fan Power at 0 Pa ranges from 29.6 to 48.0 W/1000m3/h for single-phase models, and from 31.8 to 77.1 W/1000m3/h for three-phase models. | |
| Static Pressure Range： | Performance data is fully tested up to 150 Pa for single-phase models and up to 200 Pa for three-phase models. Dedicated tube fan variants for high-pressure applications are also available upon request. | |
| Air Distance： | This parameter is not specified in the documentation. These units are specialized inline fans meant for installation inside ventilation tubes, ducts, or chimneys rather than open-air throw applications. | |
| Max Air Output： | The maximum air volume at 0 Pa ranges from 2,300 to 17,300 m³/h for single-phase models, and from 2,350 to 21,400 m³/h for three-phase models. | |
| Applications： | Primarily used in Agricultural environments (such as pig, poultry, and dairy facilities), Horticulture (greenhouses), and Industrial buildings. They support both horizontal and vertical mounting orientations. | |
| Product Category： | Tube Fans | |
| Impeller Diameter： | Standard nominal sizes span from 30 cm to 92 cm. Customized fan diameters can be fabricated between 300 mm and 963 mm to fit specific customer requirements. |
