Siemens 6ES7288-5AE01-0AA0 PLC Accessories S7-200 SMART
Brand:
Series:
S7-200 SMART
Product Type:
Analog expansion signal board
Model:
6ES7288-5AE01-0AA0
Order Number:
6ES72885AE010AA0
Description:
Siemens S7-200 SMART 6ES7288-5AE01-0AA0, analog expansion signal board, SIMATIC S7-200 SMART, analog output SB AE1, 1 AI, +/-10V, +/-5V, +/-2.5V
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | S7-200 SMART | |
| Product Description： | SIMATIC S7-200 SMART (domestic), analog output SB AE1,1 AI, +/-10V,+/-5V,+/-2.5V, oder 0 to 20mA, 11 bits + sign (voltage), 11 bits (Current mode) | |
| Product Type： | Analog expansion signal board |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Product Highlights
Rich Machine Types, More Choices
- Provide CPU modules with different types and I/O point counts. The maximum number of single - unit I/O points can reach 60, which can meet the control requirements of most small - sized automation equipment. In addition, the CPU modules are equipped with standard - type and economy - type user options. For different application requirements, the product configuration is more flexible, maximizing cost control.
Accessory Expansion, Precise Customization
- The new - designed signal board can expand communication ports, digital quantity channels, and analog quantity channels. Without additionally occupying the electrical cabinet space, the signal board expansion can better fit the user's actual configuration, improve the utilization rate of the product, and reduce the user's expansion cost at the same time.
High - Speed Chip, Outstanding Performance
- Equipped with Siemens - dedicated high - speed processor chips, the basic instruction execution time can reach 0.15μs, leading among small - sized PLCs of the same level. A powerful “core” allows you to handle frequent program logics and complex process requirements with ease.
Ethernet Interconnection, Economical and Convenient
- The CPU module is originally equipped with an Ethernet port, integrating powerful Ethernet communication functions. A common network cable can download the program to the PLC, which is convenient and fast, saving the dedicated programming cable. Through the Ethernet port, it can also communicate with other CPU modules, touch screens, and computers, making networking easy.
Three - Axis Pulse, Free Motion
- The CPU module itself integrates up to 3 channels of high - speed pulse output, with a frequency of up to 100kHz, supporting PWM/PTO output modes and multiple motion modes, and can freely set motion packages. With the convenient guide setting function, it can quickly realize functions such as equipment positioning.
Universal SD Card, Fast Update
- This machine integrates a Micro SD card slot. Using a commonly - available Micro SD card on the market can realize program updates and PLC firmware upgrades, greatly facilitating the customer engineers' service support for end - users, and also saving the inconvenience of returning the PLC firmware to the factory for upgrades.
User - Friendly Software, Efficient Programming
- On the basis of inheriting the powerful functions of Siemens programming software, more humanized designs are integrated, such as new - style menu bars, fully - movable interface windows, convenient program comment functions, and strong password protection. While experiencing powerful functions, it greatly improves development efficiency and shortens the product launch time.
Perfect Integration, Seamless Integration
- SIMATIC S7 - 200 SMART programmable controller, SIMATIC SMART LINE touch screen, SINAMICS V20 frequency converter, and SINAMICS V90 servo drive system are perfectly integrated, providing cost - effective small - sized automation solutions for OEM customers, meeting customers' all - round needs for human - machine interaction, control, and drive functions.
CPU Modules
- The new S7 - 200 SMART brings two different types of CPU modules: standard - type and economy - type, fully meeting various needs of different industries, different customers, and different equipment. The standard - type can be used as an expandable CPU module, meeting applications with relatively large I/O scale requirements and complex logic control; while the economy - type CPU module can directly meet relatively simple control requirements through a single unit.
Signal Boards
- The signal board is directly installed on the front of the CPU unit, without occupying the electrical cabinet space, and is convenient for installation and disassembly. For the needs of a small number of I/O point expansions and more communication port expansions, the newly - designed signal board can provide a more economical and flexible solution.
Network Communication
- The S7 - 200 SMART CPU module itself integrates 1 Ethernet port and 1 RS485 port. By expanding the CM01 signal board or EM DP01 module, the number of its communication ports can be increased to 4 at most, meeting the communication needs of small - sized automation equipment with touch screens, frequency converters, and other third - party equipment.
Motion Control
- The S7 - 200 SMART CPU module itself directly provides three - axis 100KHz high - speed pulse output. Through the powerful and flexible setting guide, it can be set as PWM output or motion control output, providing a unified solution for the speed and position control of stepping motors or servo motors, meeting the precise positioning needs of small - sized mechanical equipment.
Human - Machine Software, Improve Programming Efficiency
- STEP 7 - Micro/WIN SMART is the programming configuration software for S7 - 200 SMART, which can run smoothly on Windows XP SP3/Windows 7 operating systems, supporting LAD (Ladder Diagram), STL (Statement List), and FBD (Function Block Diagram) programming languages. Free conversion can be carried out between some languages. The installation file is less than 100MB. While following the programming concepts of STEP 7 - Micro/WIN, more humanized designs make programming easier to get started, and project development is more efficient.
SMART Small - Sized Automation Solution
- Siemens SIMATIC automation products are perfectly integrated with SINAMICS drive products. The cost - effective SIMATIC S7 - 200 SMART PLC, SIMATIC SMART LINE touch screen, SINAMICS V20 frequency converter, and SINAMICS V90 servo system bring perfect small - sized automation solutions for machine manufacturers, covering users' all - round needs for human - machine interaction, automation control, and drive. This solution is beneficial for users to improve the performance of machine equipment, reduce development costs, greatly shorten the launch time of machine equipment, and truly and effectively improve users' market competitiveness.
Programmable Controllers
- The CPU module has four configurations: 20I/O, 30I/O, 40I/O, and 60I/O, providing standard - type and economy - type.
- Integrate high - speed processor chips, with the bit instruction execution time reaching 0.15μs.
- Can expand communication ports, analog quantity channels, digital quantity channels, and clock keeping functions through the signal board.
- The CPU module itself integrates an Ethernet port and an RS485 serial port, supporting program download through the Ethernet port.
- Support Modbus RTU, USS, PROFIBUS - DP, and free port communication, etc.
- The unit itself can integrate up to 3 channels of 100KHz high - speed pulse output at most.
- Support program download, PLC firmware update, and factory setting restoration using a universal Micro SD card.
- Support program download, PLC firmware update, and factory setting restoration using a universal Micro SD card.
- PM207 provides high - quality DC power supply for the entire system.
