Siemens 6ES7222-1BH32-0XB0 PLC Programmable Controller S7-1200
Brand:
Series:
S7-1200
Digital Output Type:
Solid State - MOSFET
Digital Input Voltage:
-
Analog Output:
-
Digital Input:
-
Digital Output:
16
Analog Output Type:
-
Analog Input:
-
Analog Input Type:
-
Supply Voltage:
20.4-28.8VAC
Product Type:
Digital Module
Model:
6ES7222-1BH32-0XB0
Order Number:
6ES72221BH320XB0
Description:
Siemens S7-1200 6ES7222-1BH32-0XB0, power supply voltage 20.4-28.8VAC, digital output 16, digital module
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | S7-1200 | |
| Digital Output Type： | Solid State - MOSFET | |
| Digital Input Voltage： | - | |
| Analog Output： | - | |
| Digital Input： | - | |
| Digital Output： | 16 | |
| Analog Output Type： | - | |
| Analog Input： | - | |
| Analog Input Type： | - | |
| Supply Voltage： | 20.4-28.8VAC | |
| Product Type： | Digital Module |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
The S7-1200 controller is flexible and powerful, designed to control a wide range of equipment and meet diverse automation needs. Compact in design, configurable, and featuring a robust instruction set, it offers an ideal solution for various applications.
The CPU integrates a microprocessor, power supply, input/output circuits, PROFINET connectivity, high-speed motion control I/O, and onboard analog inputs into a compact, stylish housing. Once the user program is downloaded, the CPU executes logic to monitor inputs and control outputs based on program instructions, including Boolean logic, counting, timing, mathematical operations, and communication with other devices.
The CPU features a PROFINET port for network communication and supports add-on modules for PROFBUS, GPRS, RS485, or RS232 connectivity.
Safety Functions
- Password protection for configurable access rights to CPU functions
- Proprietary technology protection to hide specific code blocks
- Copy protection to restrict programs to specific memory cards or CPUs
Communication Modules
- The SIMATIC S7-1200 CPU supports up to three communication modules, including PROFBUS master/slave, RS485, and RS232 interfaces. These modules enable point-to-point serial communication using extended command libraries, USS drive protocols, and Modbus RTU master/slave protocols, all integrated with the SIMATIC STEP 7 basic engineering configuration system.
Remote Control Applications
- The CP1242-7 communication processor enables remote monitoring and control of distributed S7-1200 units via HUB, mobile networks, or the Internet.
Integrated PROFINET Interface
- The integrated PROFINET interface supports programming, HMI communication, PLC connectivity, and open Ethernet protocols. Featuring an RJ45 connector with auto-cross-over and 10/100 Mbit/s data rates, it supports TCP/IP, ISO-on-TCP, and RDS communication.
Integrated Technology
- High-speed inputs: Up to six high-speed counters (three 100 kHz, three 30 kHz) for counting and measurement
- High-speed outputs: Four 100 kHz pulse outputs for stepper/servo motor control (PLCopen motion control commands) and PWM signals for speed, position, or duty cycle control
Memory
- Shared working memory: Up to 100 KB for user commands and data
- Integrated load memory: Up to 4 MB
- Power-off retention memory: 10 KB
Scalable Design
- Signal boards: Connect to all CPUs for digital/analog I/O expansion without altering dimensions
- Signal modules: Up to eight modules on high-capacity CPUs for additional digital/analog I/O
