EBV03H001 Sanhua Refrigerant two-way electric ball valve

Name: EBV03H001 Sanhua Refrigerant two-way electric ball valve
SKU: ICX-Sanhua-EBV03H001

Brand:

Sanhua

Ambient Temperature:

-30/+55 ℃

Medium Temperature:

-40/+120 ℃

Cv:

4 m³/h

OPD L-H:

3 MPa

OPD H-L:

3 MPa

MOP:

4.3 MPa

Connections Øout:

45724 inch

ConnectionsØin:

45724 inch

Series:

EBV

Model:

EBV03H001

Order Number:

ICX-Sanhua-EBV03H001

Description:

EBV03H001,Sanhua,Refrigerant two-way electric ball valve, 配管尺寸 Ø d ODF mm:接管尺寸 Qin:45724 inch, 最高工作压力:4.3 MPa, Cv:4 m³/h, 介质温度:-40/+120 ℃, 环境温度:-30/+55 ℃

WhatsApp Inquire Now

Product parameters
Product Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Sanhua
Ambient Temperature：	-30/+55 ℃
Medium Temperature：	-40/+120 ℃
Cv：	4 m³/h
OPD L-H：	3 MPa
OPD H-L：	3 MPa
MOP：	4.3 MPa
Connections Øout：	45724 inch
ConnectionsØin：	45724 inch
Series：	EBV

Products with the same attribute : 0

Show details

Product Overview

EBV electric ball valve can adjust the refrigerant fow and cut of the refrigerant passage according to the system operating conditions, and is suitable for occasions with requirements such as fow resistance,liquid hammer,opening and closing noise and energy consumption. It can replace the pressure regulating valve, electronic expansion valve and solenoid valve at the same time, and play the role of pressure regulation and refrigerant on-of. In the R32 system, it can be used as a safety valve to immediately cut of the system circuit once a refrigerant leak is detected.

FEATURES

SOLENOID VALVE FUNCTION:

• BIDIRECTIONAL ON-OFF CONTROL

• SLOWLY OPEN AND CLOSE, AVOID WATER HAMMER AND FLUID IMPACT NOISE

• ENERGY-SAVING, ONLY ENERGY CONSUMPTION DURING THE OPERATION PROCESS

• FULL-PORT BALL VALVE CORE, LARGE FLOW, LOW PRESSURE LOSS

FLOW REGULATE FUNCTION

• FULL OPEN FLOW IS LARGE, PRESSURE LOSS IS SMALL

• HIGH PRECISION IN SMALL FLOW REGULATION

• LOW INTERNAL LEAKAGE, FULLY CLOSED CAN BE USED AS A SHUT-OFF VALVE

GENERAL SPECIFICATIONS

• Applicable for all common HCFC, HFC refrigerants such as: R134a, R404A, R407C, R410A, R32, R454B etc.

• Medium temperature TS min./max.: -40°C~+120°C

• Ambient temperature min./max.: -30°C~+70°C

• Relative humidity: Below 100% RH

• Full stroke: EBV03/EBV072800 steps EBV05/EBV09 (External Coil)4000steps EBV09 (Built-in Motor)3500steps

• Installation position:

- Coil installed in the upwards position, valve body central axis within ± 15° versusvertical axis
