TENGEN LAY5-BW3463 24V red Button
Brand:
Series:
LAY5
Lamp Holder Rated Voltage:
24VAC
Base Material:
Metal
Light Source:
With light bulb
Installation Diameter:
22.3mm
Color:
red
Function:
Reset type
Auxiliary Contacts:
2NO
Product Type:
LED flat push button
Model:
LAY5-BW3463 24V Red
Order Number:
08010120211
Description:
installation diameter 22.3mm, light source with bulb, red, reset type, metal, lamp holder rated voltage 24VAC, LED type flat head button, auxiliary contact 2NO
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | TENGEN | |
| Series： | LAY5 | |
| Lamp Holder Rated Voltage： | 24VAC | |
| Base Material： | Metal | |
| Light Source： | With light bulb | |
| Installation Diameter： | 22.3mm | |
| Color： | red | |
| Function： | Reset type | |
| Auxiliary Contacts： | 2NO | |
| Product Type： | LED flat push button |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
- The LAY5 series button switches are applicable to industrial control circuits with an AC frequency of 50Hz/60Hz, a rated working voltage of up to 380V, and a DC working voltage of 200V. They are used for line control of magnetic starters, contactors, relays, and other electrical appliances. Button switches with indicators are also suitable for occasions requiring light signal indication.
Compliance with Standards
- GB14048.5
Ambient Temperature
- Not exceeding +40°C, and the average temperature value within 24h does not exceed +35°C. The lower limit of the surrounding air temperature is -5°C.
Altitude
- Not exceeding 2000m.
Atmospheric Conditions
- When the maximum temperature is +40°C, the relative humidity of the air does not exceed 50%; at lower temperatures, a higher relative humidity is allowed. For example: reaching 90% at +20°C; special measures should be taken for condensation occasionally generated due to temperature changes.
Pollution Degree
- Grade 3.
Installation Category
- Category II.
Structural Features
- Metal buttons adopt anti - accidental operation heads, and the buttons cannot be removed from the front.
- All contacts have the dual functions of switching circuits and self - cleaning. They can still ensure the reliability of contact when used at low voltages and small currents (5V, 5mA).
- Normally open and normally closed contact groups are independent of each other, and can be combined as needed during use, facilitating replacement.
- Concealed wiring terminals, more safe and reliable. The operating heads and bases of metal head - type buttons adopt zinc - aluminum alloy, with a golden color, beautiful appearance, and firm structure.
- Illuminated buttons and signal lights uniformly use BA9S lamp bases, and different light sources can be selected as needed.
