Schneider RSL1PRPU intermediate relay

Name: Schneider RSL1PRPU intermediate relay
SKU: RSL1PRPU

Brand:

Schneider

Series:

RSL

Contact Type:

1C/O

Control Voltage:

230VAC/DC

LED Indicator:

With light

Rated Current:

Product Type:

Interface type (assembly)

Model:

RSL1PRPU

Order Number:

RSL1PRPU

Description:

Schneider intermediate relay RSL1PRPU, with light, control voltage 230VAC/DC, contact type 1C/O, rated current 6A, interface type (assembly)

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Schneider
Series：	RSL
Contact Type：	1C/O
Control Voltage：	230VAC/DC
LED Indicator：	With light
Rated Current：	6A
Product Type：	Interface type (assembly)

Products with the same attribute : 0

Show details

Series Overview

Brand - New Appearance Design

The compact shape design enables the Zelio series to achieve the most functions in electrical control cabinets with limited dimensions
Easy to apply, can be installed as standard without any adjustment, and it is also very convenient to integrate relay functions into existing equipment

Target Markets

Industrial machinery control cabinets
Distribution panel cabinets
HVAC (Heating, Ventilation and Air - Conditioning) equipment

Typical Applications

Adaptation and conversion of input/output voltage and current
As an auxiliary of PLC, perform signal processing in some automation systems

RSL Slim - type Relays

RSL slim - type relays have the advantages of compact appearance and modular design: The thin width (6mm) saves space when installed on the control cabinet rail.

RSL relays are available in two versions:

Pre - assembled version:

A single model (a fully assembled combination of relay + socket)
The standard - configured socket includes a protection circuit (protecting against reverse polarity and surges) and an LED indicator
The conductor connection provides two connection methods: Screw terminal block or spring terminal
The pre - assembled version provides a wide operating voltage range (12V - 230V)

User - assembled version:

According to user requirements, select relays (standard or silver - plated contacts) and sockets according to the operating voltage
Maintenance: RSL slim - type relays can replace the relay without disconnecting the socket wiring

RSL Slim - type Relays (Pre - assembled version)

Relay (standard contacts or silver - plated contacts): 1C/O (6A)
Clip - on fixing, easy to remove the relay from the socket
Socket: Connect conductors through terminal blocks or spring terminals
All sockets have built - in protection circuits and LED indicators

RSL Slim - type Relays (PCB type)

Five reinforced flat pins (PCB pins)
- (1) Separate type —— Control coil wiring on one side, contact wiring on the other side.

RSL Slim - type Relay Sockets

Five relay pin jacks
Clip with marking label slot
Conductors are connected through terminal blocks or spring terminals
Protection circuit and LED indicator (built - in the socket)
Rail - mounted
