ABB T16-0.23 Overload Relay

Name: ABB T16-0.23 Overload Relay
SKU: 10114912

Brand:

ABB

Series:

T16

Setting Current Range:

0.17-0.23A

Applicable Contactor:

B6/B7/VB6/VB7

Product Type:

Electric heating

Model:

T16-0.23

Order Number:

10114912

Description:

ABB overload relay T16-0.23, electric heating, suitable for contactor B6/B7/VB6/VB7, setting current range 0.17-0.23A
